M2173 XRayHRQualification
Summary
| Module | Module | M2173 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 2/9/5 | |
| PixelDefects | Total Pixel Defects | 2090 | |
| BumpBondingDefects | Bump Bonding Defects | 2019 | |
| NoisyPixels | Noisy Pixels | 21 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
19 | 0 | 99.88 | 99.35 | 0.39 | 24.5 | 72.3 | 19 | 0/0 | 0 | 1943 | 158 | 0 |
|
Chip 1
|
A
|
9 | 0 | 99.87 | 99.38 | 0.36 | 27.4 | 81.6 | 8 | 0/0 | 0 | 1978 | 169 | 0 |
|
Chip 2
|
B
|
118 | 0 | 99.87 | 99.13 | 0.48 | 20.6 | 62.8 | 118 | 0/0 | 0 | 1934 | 157 | 0 |
|
Chip 3
|
C
|
242 | 0 | 99.86 | 99.11 | 0.59 | 42.1 | 121.8 | 242 | 0/0 | 0 | 2058 | 175 | 0 |
|
Chip 4
|
C
|
276 | 0 | 99.85 | 99.14 | 1.07 | 44.9 | 130.1 | 275 | 0/0 | 0 | 2072 | 170 | 1 |
|
Chip 5
|
B
|
111 | 0 | 99.89 | 99.41 | 0.65 | 53.0 | 150.9 | 111 | 0/0 | 0 | 2144 | 161 | 0 |
|
Chip 6
|
B
|
86 | 0 | 99.89 | 99.40 | 0.65 | 54.6 | 157.2 | 86 | 0/0 | 0 | 2151 | 169 | 0 |
|
Chip 7
|
B
|
164 | 0 | 99.87 | 99.42 | 0.61 | 55.8 | 160.2 | 163 | 0/0 | 0 | 2153 | 172 | 0 |
|
Chip 8
|
C
|
205 | 0 | 99.87 | 99.37 | 0.66 | 46.1 | 134.2 | 205 | 0/0 | 0 | 2093 | 164 | 0 |
|
Chip 9
|
B
|
93 | 0 | 99.88 | 99.39 | 0.43 | 46.9 | 135.8 | 93 | 0/0 | 0 | 2086 | 162 | 0 |
|
Chip 10
|
B
|
104 | 0 | 99.88 | 99.32 | 0.59 | 50.9 | 146.1 | 104 | 0/0 | 0 | 2138 | 169 | 0 |
|
Chip 11
|
C
|
172 | 0 | 99.88 | 99.39 | 0.65 | 37.7 | 110.4 | 172 | 0/0 | 0 | 2040 | 160 | 0 |
|
Chip 12
|
B
|
144 | 0 | 99.87 | 99.37 | 0.38 | 39.6 | 115.7 | 144 | 0/0 | 0 | 2062 | 167 | 0 |
|
Chip 13
|
B
|
85 | 0 | 99.86 | 99.26 | 0.42 | 19.6 | 59.7 | 85 | 0/0 | 0 | 1941 | 161 | 0 |
|
Chip 14
|
B
|
96 | 0 | 99.87 | 99.36 | 0.4 | 20.9 | 63.1 | 96 | 0/0 | 0 | 1926 | 158 | 0 |
|
Chip 15
|
C
|
166 | 0 | 99.87 | 99.22 | 0.44 | 22.0 | 65.5 | 98 | 0/0 | 1 | 1744 | 168 | 20 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-26 | |
| TestTime | Test Time | 19:12 | |
| TestDuration | Duration | 1:25:54 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
