Test Date: 2016-02-26 19:12
Analysis date: 2016-05-26 12:05
Analysis date: 2016-05-26 12:05
M2175 XRayHRQualification
Summary
| Module | Module | M2175 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 184 | |
| BumpBondingDefects | Bump Bonding Defects | 184 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.38 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
20 | 0 | 99.88 | 99.41 | 0.43 | 33.5 | 97.9 | 20 | 0/0 | 0 | 2024 | 178 | 0 |
|
Chip 1
|
A
|
9 | 0 | 99.87 | 99.27 | 0.72 | 32.3 | 95.9 | 9 | 0/0 | 0 | 2020 | 173 | 0 |
|
Chip 2
|
A
|
13 | 0 | 99.87 | 99.19 | 0.34 | 24.7 | 75.8 | 13 | 0/0 | 0 | 1962 | 150 | 0 |
|
Chip 3
|
A
|
13 | 0 | 99.88 | 99.42 | 0.41 | 48.1 | 139.3 | 13 | 0/0 | 0 | 2140 | 161 | 0 |
|
Chip 4
|
A
|
10 | 0 | 99.89 | 99.44 | 0.6 | 54.4 | 157.5 | 10 | 0/0 | 0 | 2156 | 174 | 0 |
|
Chip 5
|
A
|
5 | 0 | 99.86 | 99.38 | 1.76 | 62.5 | 178.2 | 5 | 0/0 | 0 | 2204 | 169 | 0 |
|
Chip 6
|
A
|
11 | 0 | 99.90 | 99.39 | 0.58 | 47.4 | 140.9 | 11 | 0/0 | 0 | 2104 | 149 | 0 |
|
Chip 7
|
A
|
17 | 0 | 99.90 | 99.46 | 0.55 | 55.7 | 160.6 | 17 | 0/0 | 0 | 2172 | 162 | 0 |
|
Chip 8
|
A
|
13 | 0 | 99.89 | 99.39 | 0.52 | 52.2 | 154.0 | 13 | 0/0 | 0 | 2156 | 154 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.89 | 99.40 | 0.73 | 55.2 | 161.2 | 1 | 0/0 | 0 | 2156 | 159 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.39 | 0.48 | 66.8 | 191.1 | 0 | 0/0 | 0 | 2206 | 166 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.89 | 99.38 | 0.54 | 50.9 | 148.4 | 3 | 0/0 | 0 | 2115 | 160 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.89 | 99.43 | 0.5 | 43.9 | 129.1 | 6 | 0/0 | 0 | 2089 | 154 | 0 |
|
Chip 13
|
A
|
18 | 0 | 99.86 | 99.33 | 0.57 | 27.4 | 83.3 | 18 | 0/0 | 0 | 2001 | 158 | 0 |
|
Chip 14
|
A
|
11 | 0 | 99.88 | 99.36 | 0.52 | 33.3 | 99.0 | 11 | 0/0 | 0 | 2042 | 170 | 0 |
|
Chip 15
|
A
|
34 | 0 | 99.89 | 99.43 | 0.51 | 30.8 | 90.7 | 34 | 0/0 | 0 | 2012 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-26 | |
| TestTime | Test Time | 19:12 | |
| TestDuration | Duration | 1:25:54 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
