Test Date: 2016-03-29 10:42
Analysis date: 2016-05-26 12:25
Analysis date: 2016-05-26 12:25
M2179 XRayHRQualification
Summary
| Module | Module | M2179 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 286 | |
| BumpBondingDefects | Bump Bonding Defects | 284 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.29 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
28 | 0 | 99.86 | 99.16 | 0.51 | 26.1 | 76.6 | 28 | 0/0 | 0 | 1960 | 175 | 0 |
|
Chip 1
|
A
|
19 | 0 | 99.87 | 99.36 | 0.8 | 24.9 | 75.0 | 18 | 0/0 | 0 | 1953 | 166 | 0 |
|
Chip 2
|
A
|
33 | 0 | 99.86 | 99.42 | 0.39 | 22.8 | 69.0 | 33 | 0/0 | 0 | 1926 | 168 | 0 |
|
Chip 3
|
A
|
28 | 0 | 99.89 | 99.39 | 0.35 | 35.7 | 104.5 | 28 | 0/0 | 0 | 2039 | 159 | 0 |
|
Chip 4
|
A
|
21 | 0 | 99.88 | 99.36 | 0.54 | 42.7 | 124.4 | 21 | 0/0 | 0 | 2073 | 174 | 0 |
|
Chip 5
|
A
|
17 | 0 | 99.88 | 99.39 | 0.63 | 44.1 | 127.6 | 17 | 0/0 | 0 | 2094 | 160 | 0 |
|
Chip 6
|
A
|
25 | 0 | 99.88 | 99.37 | 0.43 | 45.9 | 132.9 | 25 | 0/0 | 0 | 2095 | 161 | 0 |
|
Chip 7
|
A
|
36 | 0 | 99.90 | 99.39 | 0.61 | 53.6 | 155.1 | 36 | 0/0 | 0 | 2159 | 171 | 0 |
|
Chip 8
|
A
|
18 | 0 | 99.88 | 99.42 | 0.31 | 41.8 | 122.3 | 18 | 0/0 | 0 | 2080 | 157 | 0 |
|
Chip 9
|
A
|
11 | 0 | 99.89 | 99.39 | 0.55 | 43.0 | 125.9 | 11 | 0/0 | 0 | 2101 | 168 | 0 |
|
Chip 10
|
A
|
5 | 0 | 99.85 | 99.11 | 0.65 | 44.5 | 129.4 | 5 | 0/0 | 0 | 2078 | 173 | 0 |
|
Chip 11
|
A
|
6 | 0 | 99.87 | 99.29 | 0.94 | 35.5 | 104.9 | 5 | 0/0 | 0 | 2002 | 167 | 1 |
|
Chip 12
|
A
|
4 | 0 | 99.85 | 99.13 | 0.75 | 29.7 | 89.5 | 4 | 0/0 | 0 | 1991 | 161 | 0 |
|
Chip 13
|
A
|
6 | 0 | 99.84 | 99.11 | 0.62 | 18.9 | 58.1 | 6 | 0/0 | 0 | 1918 | 160 | 0 |
|
Chip 14
|
A
|
8 | 0 | 99.86 | 98.99 | 0.42 | 19.8 | 60.8 | 8 | 0/0 | 0 | 1915 | 158 | 0 |
|
Chip 15
|
A
|
21 | 0 | 99.88 | 99.33 | 0.25 | 21.0 | 63.0 | 21 | 0/0 | 0 | 1944 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-03-29 | |
| TestTime | Test Time | 10:42 | |
| TestDuration | Duration | 1:24:48 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
