Test Date: 2016-03-24 13:32
Analysis date: 2016-05-26 12:57
Analysis date: 2016-05-26 12:57
M2185 XRayHRQualification
Summary
| Module | Module | M2185 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 325 | |
| BumpBondingDefects | Bump Bonding Defects | 323 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
30 | 0 | 99.85 | 99.14 | 0.56 | 24.9 | 77.0 | 30 | 0/0 | 0 | 1963 | 160 | 0 |
|
Chip 1
|
A
|
15 | 0 | 99.85 | 99.04 | 0.84 | 29.7 | 90.6 | 15 | 0/0 | 0 | 1984 | 165 | 0 |
|
Chip 2
|
B
|
73 | 0 | 99.87 | 99.42 | 0.36 | 25.6 | 79.6 | 73 | 0/0 | 0 | 1971 | 160 | 0 |
|
Chip 3
|
A
|
29 | 0 | 99.87 | 99.38 | 0.67 | 54.0 | 157.5 | 29 | 0/0 | 0 | 2183 | 174 | 0 |
|
Chip 4
|
A
|
4 | 0 | 99.87 | 99.35 | 0.43 | 46.8 | 138.8 | 4 | 0/0 | 0 | 2102 | 160 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.39 | 0.78 | 66.7 | 189.3 | 0 | 0/0 | 0 | 2193 | 164 | 1 |
|
Chip 6
|
A
|
18 | 0 | 99.85 | 99.34 | 1.13 | 59.1 | 170.8 | 18 | 0/0 | 0 | 2200 | 162 | 0 |
|
Chip 7
|
A
|
21 | 0 | 99.87 | 99.42 | 0.56 | 67.0 | 191.3 | 21 | 0/0 | 0 | 2224 | 161 | 0 |
|
Chip 8
|
A
|
14 | 0 | 99.88 | 99.40 | 0.55 | 65.0 | 186.5 | 14 | 0/0 | 0 | 2220 | 170 | 0 |
|
Chip 9
|
A
|
15 | 0 | 99.88 | 99.41 | 0.56 | 59.5 | 172.2 | 15 | 0/0 | 0 | 2158 | 162 | 0 |
|
Chip 10
|
A
|
12 | 0 | 99.88 | 99.36 | 0.66 | 55.3 | 160.1 | 11 | 0/0 | 0 | 2115 | 158 | 1 |
|
Chip 11
|
A
|
6 | 0 | 99.88 | 99.31 | 0.6 | 53.1 | 154.7 | 6 | 0/0 | 0 | 2143 | 170 | 0 |
|
Chip 12
|
A
|
25 | 0 | 99.89 | 99.40 | 0.46 | 40.7 | 121.9 | 25 | 0/0 | 0 | 2086 | 157 | 0 |
|
Chip 13
|
A
|
17 | 0 | 99.84 | 99.04 | 0.65 | 25.9 | 80.2 | 17 | 0/0 | 0 | 1981 | 156 | 0 |
|
Chip 14
|
A
|
8 | 0 | 99.86 | 99.09 | 0.82 | 25.9 | 80.0 | 8 | 0/0 | 0 | 1962 | 155 | 0 |
|
Chip 15
|
A
|
37 | 0 | 99.88 | 99.35 | 0.43 | 26.4 | 80.7 | 37 | 0/0 | 0 | 1975 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-03-24 | |
| TestTime | Test Time | 13:32 | |
| TestDuration | Duration | 1:26:44 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
