Test Date: 2016-03-24 13:32
Analysis date: 2016-05-26 13:03
Analysis date: 2016-05-26 13:03
M2186 XRayHRQualification
Summary
| Module | Module | M2186 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 30 | |
| BumpBondingDefects | Bump Bonding Defects | 28 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.33 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.89 | 99.28 | 0.56 | 29.8 | 89.5 | 3 | 0/0 | 0 | 1994 | 170 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.34 | 0.45 | 29.3 | 88.8 | 0 | 0/0 | 0 | 1999 | 168 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.26 | 0.44 | 26.2 | 80.6 | 0 | 0/0 | 0 | 1978 | 165 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.35 | 0.6 | 50.6 | 146.7 | 0 | 0/0 | 0 | 2137 | 167 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.87 | 99.38 | 0.71 | 45.8 | 135.3 | 1 | 0/0 | 0 | 2121 | 158 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.38 | 0.68 | 58.6 | 166.8 | 0 | 0/0 | 0 | 2203 | 160 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.35 | 58.4 | 168.8 | 0 | 0/0 | 0 | 2168 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.36 | 0.51 | 55.9 | 162.2 | 0 | 0/0 | 0 | 2163 | 161 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.38 | 0.65 | 61.5 | 178.5 | 1 | 0/0 | 0 | 2196 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.37 | 0.65 | 63.1 | 183.2 | 0 | 0/0 | 0 | 2204 | 164 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.34 | 0.47 | 57.5 | 166.7 | 1 | 0/0 | 0 | 2166 | 162 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.39 | 0.54 | 60.5 | 177.5 | 0 | 0/0 | 0 | 2227 | 179 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.32 | 1.21 | 52.5 | 153.9 | 0 | 0/0 | 0 | 2148 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.88 | 99.36 | 0.34 | 28.2 | 86.1 | 0 | 0/0 | 0 | 2024 | 167 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.34 | 0.53 | 30.7 | 93.3 | 0 | 0/0 | 0 | 1958 | 168 | 1 |
|
Chip 15
|
A
|
22 | 0 | 99.87 | 99.09 | 0.6 | 30.1 | 90.2 | 22 | 0/0 | 0 | 2012 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-03-24 | |
| TestTime | Test Time | 13:32 | |
| TestDuration | Duration | 1:26:44 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
