Test Date: 2016-04-14 09:29
Analysis date: 2016-05-26 14:35
Analysis date: 2016-05-26 14:35
M2201 XRayHRQualification
Summary
| Module | Module | M2201 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 20 | |
| BumpBondingDefects | Bump Bonding Defects | 12 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.87 | 99.30 | 0.49 | 29.1 | 87.9 | 2 | 0/0 | 0 | 1956 | 168 | 1 |
|
Chip 1
|
A
|
1 | 0 | 99.88 | 99.32 | 0.35 | 29.8 | 90.8 | 1 | 0/0 | 0 | 1999 | 171 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.88 | 99.27 | 0.8 | 28.2 | 86.8 | 0 | 0/0 | 0 | 1969 | 170 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.24 | 1.33 | 49.8 | 143.7 | 0 | 0/0 | 0 | 2133 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.33 | 0.56 | 49.2 | 144.9 | 0 | 0/0 | 0 | 2108 | 163 | 0 |
|
Chip 5
|
A
|
2 | 0 | 99.86 | 99.35 | 0.78 | 63.6 | 181.0 | 0 | 0/0 | 0 | 2145 | 164 | 2 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.37 | 0.65 | 58.4 | 169.4 | 0 | 0/0 | 0 | 2186 | 166 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.35 | 0.53 | 60.4 | 174.8 | 1 | 0/0 | 0 | 2189 | 157 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.89 | 99.35 | 0.82 | 60.6 | 173.8 | 1 | 0/0 | 0 | 2208 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.37 | 0.51 | 57.7 | 166.3 | 0 | 0/0 | 0 | 2185 | 165 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.36 | 0.61 | 58.8 | 167.4 | 0 | 0/0 | 0 | 2199 | 163 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.89 | 99.33 | 0.55 | 49.9 | 145.8 | 1 | 0/0 | 0 | 2128 | 166 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.33 | 0.51 | 41.2 | 123.3 | 0 | 0/0 | 0 | 2078 | 156 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 99.06 | 0.77 | 25.6 | 79.3 | 1 | 0/0 | 0 | 1985 | 164 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.38 | 0.4 | 29.9 | 90.4 | 1 | 0/0 | 0 | 2002 | 171 | 0 |
|
Chip 15
|
A
|
7 | 0 | 99.85 | 99.02 | 0.55 | 29.7 | 89.0 | 4 | 0/0 | 0 | 2005 | 185 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-14 | |
| TestTime | Test Time | 09:29 | |
| TestDuration | Duration | 1:27:20 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
