Test Date: 2016-04-25 09:19
Analysis date: 2016-05-26 15:48
Analysis date: 2016-05-26 15:48
M2212 XRayHRQualification
Summary
| Module | Module | M2212 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 49 | |
| BumpBondingDefects | Bump Bonding Defects | 45 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.34 | % |
| Noise | Mean Noise | 177 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.86 | 99.12 | 0.46 | 26.1 | 77.0 | 3 | 0/0 | 0 | 1993 | 179 | 0 |
|
Chip 1
|
A
|
6 | 0 | 99.89 | 99.39 | 0.67 | 26.4 | 79.0 | 5 | 0/0 | 0 | 1958 | 184 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.84 | 99.15 | 0.41 | 24.7 | 74.8 | 3 | 0/0 | 0 | 1939 | 190 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.90 | 99.44 | 0.57 | 43.1 | 126.0 | 3 | 0/0 | 0 | 2091 | 191 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.90 | 99.44 | 0.32 | 41.1 | 120.8 | 0 | 0/0 | 0 | 2062 | 177 | 0 |
|
Chip 5
|
A
|
2 | 0 | 99.89 | 99.43 | 0.88 | 50.9 | 146.5 | 1 | 0/0 | 0 | 2160 | 174 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.41 | 0.76 | 49.7 | 145.1 | 0 | 0/0 | 0 | 2108 | 184 | 0 |
|
Chip 7
|
A
|
5 | 0 | 99.89 | 99.40 | 0.51 | 50.9 | 148.3 | 5 | 0/0 | 0 | 2127 | 170 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.88 | 99.41 | 0.43 | 44.7 | 131.2 | 3 | 0/0 | 0 | 2075 | 179 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.40 | 0.43 | 44.9 | 131.3 | 0 | 0/0 | 0 | 2122 | 171 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.36 | 1.16 | 42.2 | 123.2 | 0 | 0/0 | 0 | 2078 | 166 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.87 | 99.39 | 0.98 | 38.1 | 112.4 | 2 | 0/0 | 0 | 2085 | 168 | 0 |
|
Chip 12
|
A
|
3 | 0 | 99.86 | 99.17 | 0.53 | 38.7 | 114.2 | 1 | 0/0 | 0 | 2068 | 190 | 2 |
|
Chip 13
|
A
|
4 | 0 | 99.86 | 99.25 | 0.44 | 18.3 | 56.7 | 4 | 0/0 | 0 | 1940 | 162 | 0 |
|
Chip 14
|
A
|
7 | 0 | 99.89 | 99.40 | 0.4 | 23.1 | 69.7 | 7 | 0/0 | 0 | 1961 | 174 | 0 |
|
Chip 15
|
A
|
8 | 0 | 99.89 | 99.34 | 0.43 | 22.3 | 66.4 | 8 | 0/0 | 0 | 1898 | 180 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 09:19 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
