Test Date: 2016-05-12 17:15
Analysis date: 2016-05-26 18:10
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
45.1765625 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
45.1765625 |
|
| medianSlope |
median Slope |
45.545 |
|
| minSlope |
min Slope |
42.309 |
|
| maxSlope |
max Slope |
47.353 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-18.2365 |
|
| medianOffset |
median Offset |
-46.319 |
|
| minOffset |
min Offset |
-141.528 |
|
| maxOffset |
max Offset |
173.306 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.4616 |
|
| medianchi2 |
median chi2 |
1.224 |
|
| minchi2 |
min chi2 |
0.034 |
|
| maxchi2 |
max chi2 |
26.929 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
-37.0 e-
|
18.2 e-
|
|
1
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-78.3 e-
|
18.0 e-
|
|
2
|
46.6 e- / Vcal
|
0.1 e- / Vcal
|
-22.8 e-
|
10.0 e-
|
|
3
|
43.3 e- / Vcal
|
0.1 e- / Vcal
|
145.9 e-
|
6.2 e-
|
|
4
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
166.7 e-
|
6.4 e-
|
|
5
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-66.9 e-
|
16.2 e-
|
|
6
|
47.4 e- / Vcal
|
0.1 e- / Vcal
|
-141.5 e-
|
17.4 e-
|
|
7
|
47.0 e- / Vcal
|
0.2 e- / Vcal
|
173.3 e-
|
17.8 e-
|
|
8
|
46.5 e- / Vcal
|
0.1 e- / Vcal
|
-123.1 e-
|
16.5 e-
|
|
9
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
-55.6 e-
|
6.2 e-
|
|
10
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
-132.1 e-
|
5.5 e-
|
|
11
|
42.3 e- / Vcal
|
0.1 e- / Vcal
|
-9.8 e-
|
19.0 e-
|
|
12
|
43.8 e- / Vcal
|
0.1 e- / Vcal
|
-92.1 e-
|
17.6 e-
|
|
13
|
42.9 e- / Vcal
|
0.2 e- / Vcal
|
84.3 e-
|
19.4 e-
|
|
14
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
-36.8 e-
|
17.8 e-
|
|
15
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-66.1 e-
|
17.5 e-
|
|
Average
|
45.2 e- / Vcal
|
|
-18.2 e-
|
|
|
Median
|
93.6 e- / Vcal
|
|
50.2 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
