Test Date: 2016-05-13 10:19
Analysis date: 2016-05-26 18:29
Analysis date: 2016-05-26 18:29
M2238 XRayHRQualification
Summary
| Module | Module | M2238 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 31 | |
| BumpBondingDefects | Bump Bonding Defects | 30 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.21 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.84 | 99.02 | 0.81 | 28.6 | 86.1 | 4 | 0/0 | 0 | 1999 | 174 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 98.95 | 0.84 | 31.1 | 94.3 | 0 | 0/0 | 0 | 1982 | 168 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.84 | 99.06 | 0.63 | 24.0 | 74.9 | 2 | 0/0 | 0 | 1955 | 159 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.85 | 99.15 | 0.74 | 52.2 | 153.3 | 1 | 0/0 | 0 | 2175 | 176 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.83 | 99.22 | 2.32 | 49.9 | 146.6 | 1 | 0/0 | 0 | 2136 | 167 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.84 | 99.26 | 0.89 | 62.0 | 178.1 | 1 | 0/0 | 0 | 2213 | 162 | 0 |
|
Chip 6
|
A
|
6 | 0 | 99.88 | 99.36 | 0.52 | 58.5 | 166.8 | 6 | 0/0 | 0 | 2179 | 156 | 0 |
|
Chip 7
|
A
|
14 | 0 | 99.87 | 99.36 | 0.37 | 65.2 | 188.1 | 13 | 0/0 | 0 | 2212 | 169 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.26 | 1.71 | 66.3 | 190.0 | 0 | 0/0 | 0 | 2236 | 168 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.34 | 0.52 | 58.1 | 167.9 | 0 | 0/0 | 0 | 2164 | 163 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.28 | 0.81 | 67.6 | 193.8 | 0 | 0/0 | 0 | 2212 | 171 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.36 | 0.69 | 52.9 | 154.9 | 0 | 0/0 | 0 | 2171 | 168 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.01 | 0.92 | 49.1 | 144.4 | 0 | 0/0 | 0 | 2104 | 169 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.28 | 0.46 | 26.1 | 80.4 | 0 | 0/0 | 0 | 1967 | 163 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.23 | 0.63 | 30.9 | 93.2 | 0 | 0/0 | 0 | 2001 | 176 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.86 | 99.29 | 0.38 | 29.4 | 88.1 | 2 | 0/0 | 0 | 2004 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-13 | |
| TestTime | Test Time | 10:19 | |
| TestDuration | Duration | 1:27:40 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
