Test Date: 2016-05-13 10:19
Analysis date: 2016-05-26 18:44
Analysis date: 2016-05-26 18:44
M2240 XRayHRQualification
Summary
| Module | Module | M2240 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 23 | |
| BumpBondingDefects | Bump Bonding Defects | 20 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.20 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
7 | 0 | 99.86 | 99.10 | 1.02 | 21.3 | 65.8 | 6 | 0/0 | 0 | 1922 | 184 | 0 |
|
Chip 1
|
A
|
3 | 0 | 99.85 | 99.10 | 0.44 | 19.5 | 61.4 | 2 | 0/0 | 0 | 1922 | 175 | 1 |
|
Chip 2
|
A
|
1 | 0 | 99.87 | 99.16 | 0.33 | 16.9 | 53.4 | 1 | 0/0 | 0 | 1907 | 163 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.90 | 99.35 | 0.49 | 33.4 | 100.7 | 1 | 0/0 | 0 | 2044 | 176 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.84 | 99.04 | 0.55 | 34.6 | 104.0 | 2 | 0/0 | 0 | 2028 | 175 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.25 | 0.72 | 41.9 | 122.6 | 0 | 0/0 | 0 | 2077 | 172 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.34 | 0.51 | 36.1 | 107.5 | 0 | 0/0 | 0 | 2033 | 164 | 0 |
|
Chip 7
|
A
|
5 | 0 | 99.86 | 99.25 | 0.69 | 40.5 | 120.3 | 5 | 0/0 | 0 | 2042 | 173 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.33 | 0.52 | 43.5 | 128.3 | 1 | 0/0 | 0 | 2086 | 169 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.37 | 0.46 | 38.2 | 114.4 | 0 | 0/0 | 0 | 2055 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.24 | 0.54 | 43.6 | 127.9 | 0 | 0/0 | 0 | 2090 | 164 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.33 | 0.51 | 41.2 | 122.8 | 0 | 0/0 | 0 | 2095 | 176 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.03 | 1.15 | 36.6 | 110.0 | 0 | 0/0 | 0 | 2043 | 166 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.83 | 99.02 | 0.64 | 21.2 | 66.2 | 1 | 0/0 | 0 | 1944 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.01 | 0.54 | 21.4 | 66.8 | 0 | 0/0 | 0 | 1904 | 169 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.88 | 99.33 | 0.33 | 21.1 | 65.4 | 1 | 0/0 | 0 | 1922 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-05-13 | |
| TestTime | Test Time | 10:19 | |
| TestDuration | Duration | 1:27:40 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
