Test Date: 2016-06-10 13:39
Analysis date: 2016-06-10 15:32
Analysis date: 2016-06-10 15:32
M2251 XRayHRQualification
Summary
| Module | Module | M2251 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 15 | |
| BumpBondingDefects | Bump Bonding Defects | 14 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.85 | 99.08 | 0.39 | 18.8 | 58.1 | 4 | 0/0 | 0 | 1909 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.30 | 0.43 | 22.3 | 68.1 | 0 | 0/0 | 0 | 1957 | 168 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.86 | 99.10 | 0.44 | 17.4 | 54.7 | 1 | 0/0 | 0 | 1875 | 155 | 1 |
|
Chip 3
|
A
|
2 | 0 | 99.88 | 99.37 | 0.99 | 32.8 | 97.9 | 2 | 0/0 | 0 | 2044 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.34 | 0.58 | 34.1 | 102.5 | 0 | 0/0 | 0 | 2037 | 159 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.31 | 0.44 | 38.9 | 114.7 | 0 | 0/0 | 0 | 2065 | 153 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.30 | 0.65 | 39.9 | 117.7 | 0 | 0/0 | 0 | 2080 | 159 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.89 | 99.40 | 0.46 | 44.3 | 129.8 | 2 | 0/0 | 0 | 2105 | 162 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.37 | 0.46 | 49.4 | 144.3 | 0 | 0/0 | 0 | 2155 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.35 | 0.56 | 45.2 | 132.4 | 0 | 0/0 | 0 | 2094 | 157 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.33 | 0.46 | 44.8 | 131.8 | 0 | 0/0 | 0 | 2103 | 157 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.35 | 0.41 | 43.0 | 126.6 | 0 | 0/0 | 0 | 2103 | 163 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.28 | 0.6 | 39.2 | 115.2 | 0 | 0/0 | 0 | 2057 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.02 | 0.49 | 22.0 | 67.5 | 0 | 0/0 | 0 | 1950 | 158 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.87 | 99.34 | 0.52 | 24.9 | 75.6 | 1 | 0/0 | 0 | 1971 | 168 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.86 | 99.04 | 0.58 | 23.6 | 71.5 | 4 | 0/0 | 0 | 1963 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-10 | |
| TestTime | Test Time | 13:39 | |
| TestDuration | Duration | 1:27:40 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
