Test Date: 2016-06-13 10:11
Analysis date: 2016-06-13 11:33
Analysis date: 2016-06-13 11:33
M2252 XRayHRQualification
Summary
| Module | Module | M2252 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 74 | |
| BumpBondingDefects | Bump Bonding Defects | 73 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.24 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
15 | 0 | 99.86 | 99.26 | 0.45 | 30.1 | 89.6 | 15 | 0/0 | 0 | 1998 | 167 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.13 | 0.68 | 33.2 | 99.4 | 0 | 0/0 | 0 | 1995 | 178 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.30 | 0.57 | 29.2 | 88.7 | 0 | 0/0 | 0 | 1986 | 170 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.28 | 0.52 | 55.7 | 163.0 | 0 | 0/0 | 0 | 2178 | 172 | 0 |
|
Chip 4
|
A
|
8 | 0 | 99.86 | 99.31 | 0.72 | 50.2 | 147.1 | 8 | 0/0 | 0 | 2125 | 159 | 0 |
|
Chip 5
|
A
|
32 | 0 | 99.87 | 99.37 | 0.64 | 62.2 | 178.4 | 32 | 0/0 | 0 | 2199 | 159 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.34 | 0.55 | 61.8 | 180.0 | 1 | 0/0 | 0 | 2239 | 155 | 0 |
|
Chip 7
|
A
|
16 | 0 | 99.88 | 99.28 | 0.93 | 59.8 | 173.3 | 16 | 0/0 | 0 | 2161 | 162 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.33 | 0.67 | 66.0 | 191.8 | 0 | 0/0 | 0 | 2179 | 159 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.24 | 0.61 | 60.3 | 174.7 | 0 | 0/0 | 0 | 2167 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.26 | 0.53 | 66.5 | 191.2 | 0 | 0/0 | 0 | 2252 | 152 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.22 | 0.71 | 55.4 | 162.2 | 0 | 0/0 | 0 | 2145 | 159 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.00 | 0.92 | 51.0 | 149.4 | 0 | 0/0 | 0 | 2126 | 162 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.22 | 0.46 | 30.7 | 93.6 | 1 | 0/0 | 0 | 2011 | 164 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.08 | 0.81 | 34.0 | 101.4 | 0 | 0/0 | 0 | 2035 | 173 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.24 | 0.68 | 34.8 | 102.3 | 0 | 0/0 | 0 | 2013 | 176 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-13 | |
| TestTime | Test Time | 10:11 | |
| TestDuration | Duration | 1:15:53 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 5 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
