Test Date: 2016-06-15 15:42
Analysis date: 2016-06-15 18:02
Analysis date: 2016-06-15 18:02
M2253 XRayHRQualification
Summary
| Module | Module | M2253 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 33 | |
| BumpBondingDefects | Bump Bonding Defects | 28 | |
| NoisyPixels | Noisy Pixels | 5 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.23 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
9 | 0 | 99.86 | 99.04 | 0.5 | 21.3 | 65.1 | 9 | 0/0 | 0 | 1908 | 165 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.85 | 98.99 | 0.59 | 24.6 | 74.9 | 2 | 0/0 | 0 | 1949 | 180 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 98.98 | 0.63 | 24.3 | 73.2 | 0 | 0/0 | 0 | 1954 | 173 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.88 | 99.40 | 0.44 | 37.8 | 111.6 | 3 | 0/0 | 0 | 2055 | 170 | 0 |
|
Chip 4
|
A
|
3 | 0 | 99.85 | 99.17 | 0.82 | 37.4 | 110.5 | 2 | 0/0 | 0 | 2031 | 169 | 1 |
|
Chip 5
|
A
|
1 | 0 | 99.87 | 99.40 | 0.69 | 55.3 | 159.7 | 1 | 0/0 | 0 | 2178 | 173 | 0 |
|
Chip 6
|
A
|
5 | 0 | 99.88 | 99.40 | 0.48 | 54.1 | 158.4 | 4 | 0/0 | 0 | 2133 | 171 | 1 |
|
Chip 7
|
A
|
5 | 0 | 99.88 | 99.39 | 0.51 | 53.5 | 153.8 | 5 | 0/0 | 0 | 2144 | 166 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.31 | 0.5 | 50.4 | 145.7 | 0 | 0/0 | 0 | 2137 | 175 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.34 | 0.54 | 45.1 | 131.7 | 0 | 0/0 | 0 | 2083 | 174 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.33 | 0.43 | 47.1 | 136.0 | 0 | 0/0 | 0 | 2114 | 176 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.06 | 0.6 | 32.6 | 97.7 | 0 | 0/0 | 0 | 2021 | 163 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.21 | 0.52 | 31.0 | 93.3 | 0 | 0/0 | 0 | 2002 | 164 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.89 | 99.37 | 0.3 | 19.7 | 60.7 | 0 | 0/0 | 0 | 1886 | 175 | 1 |
|
Chip 14
|
A
|
2 | 0 | 99.86 | 98.98 | 0.41 | 19.1 | 59.0 | 0 | 0/0 | 0 | 1881 | 171 | 2 |
|
Chip 15
|
A
|
2 | 0 | 99.89 | 99.29 | 0.32 | 19.6 | 60.3 | 2 | 0/0 | 0 | 1929 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-15 | |
| TestTime | Test Time | 15:42 | |
| TestDuration | Duration | 1:28:3 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
