Test Date: 2016-06-15 15:42
Analysis date: 2016-06-15 17:22
Analysis date: 2016-06-15 17:22
M2254 XRayHRQualification
Summary
| Module | Module | M2254 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.28 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.00 | 0.59 | 32.0 | 95.4 | 0 | 0/0 | 0 | 2013 | 178 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.31 | 0.87 | 31.0 | 93.3 | 1 | 0/0 | 0 | 2029 | 171 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.07 | 0.61 | 24.8 | 77.7 | 0 | 0/0 | 0 | 1971 | 160 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.32 | 0.63 | 49.7 | 145.0 | 0 | 0/0 | 0 | 2139 | 168 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.35 | 0.43 | 47.8 | 140.3 | 0 | 0/0 | 0 | 2120 | 162 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.10 | 0.75 | 59.3 | 169.8 | 0 | 0/0 | 0 | 2210 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.36 | 0.56 | 57.2 | 164.2 | 0 | 0/0 | 0 | 2189 | 160 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.32 | 0.61 | 68.8 | 196.5 | 0 | 0/0 | 0 | 2234 | 161 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.86 | 99.42 | 0.51 | 62.4 | 179.9 | 4 | 0/0 | 0 | 2220 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.38 | 0.53 | 63.1 | 182.0 | 0 | 0/0 | 0 | 2206 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.35 | 0.68 | 54.9 | 160.3 | 0 | 0/0 | 0 | 2143 | 153 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.35 | 0.48 | 53.1 | 154.9 | 0 | 0/0 | 0 | 2177 | 165 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.28 | 0.48 | 43.5 | 128.7 | 0 | 0/0 | 0 | 2096 | 159 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.85 | 99.16 | 0.4 | 28.2 | 86.3 | 2 | 0/0 | 0 | 2019 | 169 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.33 | 0.44 | 30.6 | 92.3 | 0 | 0/0 | 0 | 2015 | 171 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.88 | 99.32 | 0.5 | 30.5 | 91.1 | 1 | 0/0 | 0 | 2006 | 180 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-15 | |
| TestTime | Test Time | 15:42 | |
| TestDuration | Duration | 1:28:3 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 17 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 5 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
