Test Date: 2016-06-16 14:58
Analysis date: 2016-06-16 17:08
Analysis date: 2016-06-16 17:08
M2257 XRayHRQualification
Summary
| Module | Module | M2257 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 67 | |
| BumpBondingDefects | Bump Bonding Defects | 63 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
18 | 0 | 99.86 | 99.18 | 0.59 | 76.0 | 18 | 25.6 | 0/0 | 0 | 1957 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.31 | 0.58 | 77.1 | 0 | 25.6 | 0/0 | 0 | 1982 | 165 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.87 | 99.31 | 0.3 | 67.5 | 1 | 22.1 | 0/0 | 0 | 1954 | 157 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.35 | 0.6 | 122.2 | 0 | 42.3 | 0/0 | 0 | 2094 | 170 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.6 | 121.9 | 0 | 41.7 | 0/0 | 0 | 2091 | 164 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.31 | 0.57 | 147.8 | 0 | 51.6 | 0/0 | 0 | 2123 | 166 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.33 | 0.7 | 138.2 | 0 | 47.8 | 0/0 | 0 | 2084 | 160 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.28 | 0.57 | 147.4 | 0 | 50.8 | 0/0 | 0 | 2118 | 162 | 0 |
|
Chip 8
|
A
|
2 | 0 | 99.87 | 99.31 | 0.53 | 144.5 | 2 | 50.1 | 0/0 | 0 | 2131 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.34 | 0.51 | 118.3 | 0 | 39.9 | 0/0 | 0 | 2056 | 155 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.29 | 0.5 | 130.9 | 0 | 45.5 | 0/0 | 0 | 2105 | 152 | 0 |
|
Chip 11
|
A
|
8 | 0 | 99.87 | 99.32 | 0.79 | 113.6 | 5 | 38.6 | 0/0 | 0 | 2076 | 162 | 1 |
|
Chip 12
|
A
|
2 | 0 | 99.88 | 99.33 | 0.61 | 110.7 | 2 | 37.7 | 0/0 | 0 | 2065 | 165 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 99.05 | 0.49 | 66.5 | 1 | 21.9 | 0/0 | 0 | 1932 | 165 | 0 |
|
Chip 14
|
A
|
9 | 0 | 99.84 | 98.99 | 0.68 | 69.3 | 9 | 22.9 | 0/0 | 0 | 1967 | 161 | 0 |
|
Chip 15
|
A
|
25 | 0 | 99.85 | 99.25 | 0.7 | 74.1 | 25 | 25.0 | 0/0 | 0 | 1974 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-16 | |
| TestTime | Test Time | 14:58 | |
| TestDuration | Duration | 1:26:58 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
