Test Date: 2016-06-16 14:58
Analysis date: 2016-06-16 16:41
Analysis date: 2016-06-16 16:41
M2261 XRayHRQualification
Summary
| Module | Module | M2261 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 6 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.31 | % |
| Noise | Mean Noise | 172 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.31 | 0.31 | 20.6 | 62.7 | 0 | 0/0 | 0 | 1940 | 168 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.89 | 99.37 | 0.3 | 19.8 | 61.6 | 0 | 0/0 | 0 | 1924 | 160 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.15 | 0.4 | 19.8 | 60.8 | 0 | 0/0 | 0 | 1923 | 166 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.08 | 0.62 | 31.5 | 94.6 | 0 | 0/0 | 0 | 2009 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.30 | 0.61 | 36.9 | 109.7 | 0 | 0/0 | 0 | 2027 | 177 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.25 | 0.83 | 50.3 | 144.4 | 0 | 0/0 | 0 | 2130 | 179 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.41 | 0.42 | 47.9 | 138.9 | 0 | 0/0 | 0 | 2123 | 170 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.43 | 0.42 | 50.7 | 147.1 | 0 | 0/0 | 0 | 2147 | 179 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.39 | 0.8 | 51.2 | 147.3 | 0 | 0/0 | 0 | 2109 | 174 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.32 | 0.54 | 57.8 | 167.8 | 0 | 0/0 | 0 | 2171 | 187 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.36 | 0.52 | 55.6 | 159.4 | 0 | 0/0 | 0 | 2144 | 174 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.31 | 0.5 | 41.3 | 121.7 | 0 | 0/0 | 0 | 2071 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.33 | 0.68 | 39.6 | 116.6 | 0 | 0/0 | 0 | 2066 | 170 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.86 | 99.35 | 0.3 | 23.9 | 72.5 | 0 | 0/0 | 0 | 1866 | 172 | 3 |
|
Chip 14
|
A
|
0 | 0 | 99.89 | 99.35 | 0.61 | 23.7 | 72.1 | 0 | 0/0 | 0 | 1958 | 166 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.88 | 99.30 | 0.39 | 24.1 | 72.7 | 0 | 0/0 | 0 | 1914 | 174 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-16 | |
| TestTime | Test Time | 14:58 | |
| TestDuration | Duration | 1:26:58 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
