Test Date: 2016-06-30 09:26
Analysis date: 2016-06-30 13:59
Analysis date: 2016-06-30 13:59
M2267 XRayHRQualification
Summary
| Module | Module | M2267 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 162 | |
| BumpBondingDefects | Bump Bonding Defects | 161 | |
| NoisyPixels | Noisy Pixels | 76 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 50/120 | 99.88/99.32 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.30 | 0.48 | 91.8 | 0 | 30.6 | 0/0 | 0 | 2009 | 178 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.31 | 0.48 | 91.5 | 0 | 30.1 | 0/0 | 0 | 1991 | 175 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.31 | 0.4 | 82.2 | 0 | 26.8 | 0/0 | 0 | 1982 | 169 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.32 | 0.73 | 151.0 | 0 | 51.7 | 0/0 | 0 | 2141 | 176 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.88 | 99.36 | 0.48 | 142.9 | 2 | 48.6 | 0/0 | 0 | 2115 | 178 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.32 | 0.62 | 189.4 | 0 | 66.3 | 0/0 | 0 | 2251 | 171 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.90 | 99.34 | 0.53 | 184.7 | 0 | 63.8 | 0/0 | 0 | 2215 | 173 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.36 | 0.7 | 191.8 | 0 | 66.9 | 0/0 | 0 | 2220 | 169 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.36 | 0.55 | 172.9 | 0 | 60.0 | 0/0 | 0 | 2196 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.32 | 0.54 | 175.2 | 0 | 61.0 | 0/0 | 0 | 2200 | 159 | 0 |
|
Chip 10
|
C
|
160 | 1 | 99.88 | 99.35 | 0.54 | 172.8 | 159 | 61.1 | 0/0 | 2 | 1533 | 173 | 76 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.36 | 0.49 | 151.4 | 0 | 52.3 | 0/0 | 0 | 2162 | 168 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.34 | 0.58 | 135.8 | 0 | 46.5 | 0/0 | 0 | 2123 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.30 | 0.5 | 79.4 | 0 | 26.0 | 0/0 | 0 | 2006 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.29 | 0.63 | 92.1 | 0 | 30.5 | 0/0 | 0 | 1994 | 178 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.26 | 0.56 | 79.5 | 0 | 26.1 | 0/0 | 0 | 1970 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-06-30 | |
| TestTime | Test Time | 09:26 | |
| TestDuration | Duration | 1:24:44 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.1-7-g5388ca4 on branch psi46master
