Test Date: 2016-07-04 10:02
Analysis date: 2016-07-04 11:41
Analysis date: 2016-07-04 11:41
M2270 XRayHRQualification
Summary
| Module | Module | M2270 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.27 | % |
| Noise | Mean Noise | 186 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.31 | 0.44 | 29.1 | 86.8 | 0 | 0/0 | 0 | 2020 | 176 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.10 | 0.69 | 31.3 | 94.1 | 0 | 0/0 | 0 | 2023 | 183 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.39 | 0.45 | 26.8 | 81.9 | 0 | 0/0 | 0 | 2010 | 185 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.40 | 0.58 | 50.3 | 146.8 | 0 | 0/0 | 0 | 2171 | 188 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.37 | 0.95 | 56.6 | 166.1 | 0 | 0/0 | 0 | 2171 | 205 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.36 | 0.64 | 59.5 | 170.2 | 0 | 0/0 | 0 | 2205 | 167 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.38 | 0.34 | 59.6 | 173.5 | 0 | 0/0 | 0 | 2199 | 174 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.89 | 99.38 | 0.64 | 62.9 | 181.9 | 0 | 0/0 | 0 | 2183 | 177 | 1 |
|
Chip 8
|
A
|
2 | 0 | 99.85 | 99.28 | 0.77 | 66.3 | 193.8 | 0 | 0/0 | 0 | 2180 | 186 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.27 | 0.47 | 64.2 | 187.0 | 0 | 0/0 | 0 | 2225 | 171 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.27 | 1.06 | 66.2 | 188.8 | 0 | 0/0 | 0 | 2230 | 178 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.25 | 0.7 | 53.8 | 157.3 | 0 | 0/0 | 0 | 2161 | 181 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.25 | 0.83 | 50.3 | 146.1 | 0 | 0/0 | 0 | 2169 | 187 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 99.11 | 0.53 | 30.7 | 93.7 | 0 | 0/0 | 0 | 1993 | 220 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.22 | 0.66 | 31.8 | 95.9 | 0 | 0/0 | 0 | 2020 | 199 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.84 | 98.99 | 0.7 | 31.1 | 92.5 | 0 | 0/0 | 0 | 2001 | 192 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-07-04 | |
| TestTime | Test Time | 10:02 | |
| TestDuration | Duration | 1:24:30 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.1-7-g5388ca4 on branch psi46master
