Test Date: 2016-07-25 09:53
Analysis date: 2016-07-25 11:45
Analysis date: 2016-07-25 11:45
M2276 XRayHRQualification
Summary
| Module | Module | M2276 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.18 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.05 | 0.84 | 32.8 | 96.3 | 0 | 0/0 | 0 | 2005 | 171 | 0 |
|
Chip 1
|
A
|
4 | 0 | 99.81 | 98.91 | 2.35 | 33.5 | 99.8 | 0 | 0/0 | 0 | 2008 | 171 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.30 | 0.44 | 27.9 | 84.5 | 0 | 0/0 | 0 | 1959 | 165 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.18 | 0.57 | 49.1 | 142.3 | 0 | 0/0 | 0 | 2132 | 163 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.31 | 0.53 | 53.0 | 154.5 | 0 | 0/0 | 0 | 2167 | 167 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.25 | 0.73 | 64.1 | 184.0 | 0 | 0/0 | 0 | 2216 | 160 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.31 | 0.66 | 59.5 | 173.3 | 0 | 0/0 | 0 | 2189 | 159 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.26 | 0.79 | 56.7 | 165.5 | 1 | 0/0 | 0 | 2145 | 159 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.30 | 0.75 | 62.6 | 181.8 | 0 | 0/0 | 0 | 2169 | 168 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.31 | 0.66 | 56.0 | 162.7 | 0 | 0/0 | 0 | 2144 | 157 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.34 | 0.63 | 67.3 | 193.7 | 0 | 0/0 | 0 | 2231 | 158 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.28 | 0.71 | 51.2 | 149.4 | 0 | 0/0 | 0 | 2140 | 157 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.20 | 0.68 | 51.0 | 148.7 | 0 | 0/0 | 0 | 2107 | 165 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 98.95 | 1.03 | 29.3 | 88.4 | 0 | 0/0 | 0 | 2004 | 164 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 98.93 | 0.64 | 32.9 | 98.0 | 0 | 0/0 | 0 | 1974 | 163 | 1 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.06 | 0.69 | 30.4 | 90.0 | 0 | 0/0 | 0 | 1990 | 156 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-07-25 | |
| TestTime | Test Time | 09:53 | |
| TestDuration | Duration | 1:32:29 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
