Test Date: 2016-08-10 16:30
Analysis date: 2016-08-12 11:19
Analysis date: 2016-08-12 11:19
M2281 XRayHRQualification
Summary
| Module | Module | M2281 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 138 | |
| BumpBondingDefects | Bump Bonding Defects | 46 | |
| NoisyPixels | Noisy Pixels | 53 | |
| HotPixelDefects | Hot Pixels | 86 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.18 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 98.95 | 0.75 | 28.8 | 87.0 | 1 | 0/0 | 0 | 1974 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.88 | 0.92 | 32.4 | 98.2 | 0 | 0/0 | 0 | 2018 | 174 | 0 |
|
Chip 2
|
B
|
89 | 0 | 99.84 | 99.24 | 0.8 | 28.6 | 88.3 | 0 | 0/0 | 0 | 904 | 172 | 50 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.29 | 0.59 | 48.3 | 143.3 | 0 | 0/0 | 0 | 2108 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.28 | 0.52 | 49.0 | 146.3 | 0 | 0/0 | 0 | 2080 | 164 | 0 |
|
Chip 5
|
A
|
4 | 0 | 99.85 | 99.24 | 1.18 | 67.2 | 195.8 | 4 | 0/0 | 0 | 2211 | 165 | 0 |
|
Chip 6
|
A
|
7 | 0 | 99.86 | 99.29 | 0.65 | 58.4 | 170.1 | 7 | 0/0 | 0 | 2176 | 160 | 0 |
|
Chip 7
|
A
|
7 | 0 | 99.88 | 99.28 | 0.64 | 62.6 | 181.5 | 7 | 0/0 | 0 | 2185 | 158 | 0 |
|
Chip 8
|
A
|
27 | 0 | 99.84 | 99.16 | 1.07 | 66.3 | 193.4 | 24 | 0/0 | 0 | 2095 | 160 | 3 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.32 | 0.74 | 63.0 | 184.1 | 0 | 0/0 | 0 | 2191 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.30 | 0.56 | 66.1 | 191.1 | 0 | 0/0 | 0 | 2222 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.25 | 0.57 | 51.0 | 151.5 | 0 | 0/0 | 0 | 2135 | 158 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.87 | 99.24 | 0.59 | 48.4 | 144.5 | 2 | 0/0 | 0 | 2093 | 167 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.84 | 98.94 | 0.56 | 25.0 | 78.2 | 1 | 0/0 | 0 | 1958 | 152 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 98.92 | 0.75 | 32.0 | 96.9 | 0 | 0/0 | 0 | 1997 | 164 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.29 | 0.46 | 30.2 | 91.3 | 0 | 0/0 | 0 | 2011 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 16:30 | |
| TestDuration | Duration | 1:26:52 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
