Test Date: 2016-08-10 11:12
Analysis date: 2016-08-10 15:57
Analysis date: 2016-08-10 15:57
M2289 XRayHRQualification
Summary
| Module | Module | M2289 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 19 | |
| BumpBondingDefects | Bump Bonding Defects | 19 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.00 | 0.58 | 91.1 | 0 | 30.6 | 0/0 | 0 | 1977 | 174 | 0 |
|
Chip 1
|
A
|
3 | 0 | 99.82 | 98.98 | 0.63 | 96.8 | 3 | 32.5 | 0/0 | 0 | 1996 | 174 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.28 | 0.42 | 86.3 | 0 | 28.6 | 0/0 | 0 | 1945 | 165 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.26 | 0.85 | 146.4 | 0 | 50.1 | 0/0 | 0 | 2098 | 164 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.12 | 0.95 | 148.2 | 0 | 50.6 | 0/0 | 0 | 2101 | 163 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.86 | 99.28 | 0.54 | 182.2 | 1 | 64.0 | 0/0 | 0 | 2190 | 156 | 0 |
|
Chip 6
|
A
|
10 | 0 | 99.87 | 99.28 | 0.58 | 156.5 | 10 | 53.7 | 0/0 | 0 | 2142 | 162 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.28 | 0.95 | 176.3 | 1 | 60.3 | 0/0 | 0 | 2173 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.35 | 0.64 | 197.4 | 0 | 67.1 | 0/0 | 0 | 2191 | 177 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.87 | 99.30 | 0.59 | 180.0 | 1 | 62.0 | 0/0 | 0 | 2159 | 165 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.86 | 99.28 | 0.59 | 183.7 | 1 | 64.4 | 0/0 | 0 | 2190 | 157 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.35 | 0.59 | 155.7 | 0 | 53.1 | 0/0 | 0 | 2153 | 163 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.32 | 0.6 | 151.2 | 1 | 51.7 | 0/0 | 0 | 2119 | 169 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.32 | 0.43 | 95.9 | 0 | 31.8 | 0/0 | 0 | 2013 | 176 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.33 | 0.46 | 107.7 | 1 | 36.2 | 0/0 | 0 | 2039 | 188 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.00 | 0.7 | 101.4 | 0 | 34.3 | 0/0 | 0 | 2022 | 187 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-10 | |
| TestTime | Test Time | 11:12 | |
| TestDuration | Duration | 1:32:15 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 17 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 5 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 4 |
