Test Date: 2016-08-22 17:23
Analysis date: 2016-08-22 20:54
Analysis date: 2016-08-22 20:54
M2292 XRayHRQualification
Summary
| Module | Module | M2292 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 42 | |
| BumpBondingDefects | Bump Bonding Defects | 32 | |
| NoisyPixels | Noisy Pixels | 6 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.22 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 98.95 | 0.73 | 30.8 | 94.5 | 0 | 0/0 | 0 | 1952 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.23 | 0.78 | 33.1 | 101.4 | 0 | 0/0 | 0 | 1999 | 168 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.84 | 99.20 | 1.26 | 29.6 | 91.5 | 0 | 0/0 | 0 | 1944 | 174 | 1 |
|
Chip 3
|
A
|
2 | 0 | 99.86 | 99.28 | 0.6 | 49.3 | 150.6 | 2 | 0/0 | 0 | 2074 | 163 | 0 |
|
Chip 4
|
A
|
4 | 0 | 99.86 | 99.27 | 1.04 | 50.3 | 155.4 | 3 | 0/0 | 0 | 2079 | 166 | 0 |
|
Chip 5
|
A
|
10 | 0 | 99.86 | 99.29 | 0.77 | 64.4 | 197.0 | 7 | 0/0 | 0 | 2005 | 172 | 3 |
|
Chip 6
|
A
|
2 | 0 | 99.88 | 99.30 | 0.56 | 59.0 | 185.9 | 1 | 0/0 | 0 | 2054 | 163 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.28 | 0.8 | 58.5 | 182.2 | 0 | 0/0 | 0 | 2122 | 160 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.29 | 0.44 | 59.6 | 185.7 | 1 | 0/0 | 0 | 2115 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.31 | 0.76 | 56.7 | 176.8 | 0 | 0/0 | 0 | 2081 | 161 | 0 |
|
Chip 10
|
A
|
18 | 0 | 99.87 | 99.26 | 0.65 | 62.8 | 191.6 | 18 | 0/0 | 0 | 2134 | 161 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.32 | 0.48 | 50.6 | 153.2 | 0 | 0/0 | 0 | 2137 | 161 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.25 | 0.97 | 47.4 | 143.8 | 0 | 0/0 | 0 | 2074 | 162 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.15 | 0.56 | 28.2 | 87.9 | 0 | 0/0 | 0 | 1965 | 163 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.15 | 0.7 | 32.4 | 99.3 | 0 | 0/0 | 0 | 1982 | 165 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.84 | 98.98 | 0.68 | 30.5 | 92.2 | 0 | 0/0 | 0 | 1946 | 167 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-22 | |
| TestTime | Test Time | 17:23 | |
| TestDuration | Duration | 1:35:18 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
