Test Date: 2016-09-05 09:50
Analysis date: 2016-09-05 11:40
Analysis date: 2016-09-05 11:40
M2298 XRayHRQualification
Summary
| Module | Module | M2298 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 174 | |
| BumpBondingDefects | Bump Bonding Defects | 172 | |
| NoisyPixels | Noisy Pixels | 59 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 50/120 | 99.86/99.18 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 98.92 | 0.62 | 23.2 | 69.7 | 0 | 0/0 | 0 | 1950 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.26 | 0.48 | 24.6 | 74.6 | 0 | 0/0 | 0 | 1963 | 161 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.25 | 0.49 | 23.7 | 72.0 | 0 | 0/0 | 0 | 1944 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.30 | 0.5 | 39.8 | 117.2 | 0 | 0/0 | 0 | 2065 | 160 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.27 | 0.76 | 44.8 | 131.3 | 0 | 0/0 | 0 | 2099 | 173 | 0 |
|
Chip 5
|
C
|
161 | 1 | 99.86 | 99.32 | 0.54 | 53.3 | 154.5 | 161 | 0/0 | 2 | 1792 | 171 | 57 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.30 | 0.6 | 50.7 | 147.6 | 0 | 0/0 | 0 | 2148 | 161 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.85 | 99.08 | 0.71 | 60.6 | 176.9 | 2 | 0/0 | 0 | 2207 | 176 | 0 |
|
Chip 8
|
A
|
4 | 0 | 99.86 | 99.26 | 0.42 | 51.2 | 148.7 | 2 | 0/0 | 0 | 2066 | 167 | 2 |
|
Chip 9
|
A
|
2 | 0 | 99.85 | 99.08 | 0.95 | 45.3 | 132.2 | 2 | 0/0 | 0 | 2107 | 163 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.45 | 46.3 | 134.7 | 0 | 0/0 | 0 | 2104 | 159 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.84 | 99.05 | 0.83 | 42.2 | 125.1 | 1 | 0/0 | 0 | 2074 | 176 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.86 | 99.23 | 0.6 | 34.5 | 102.5 | 1 | 0/0 | 0 | 2042 | 162 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.26 | 0.52 | 19.8 | 60.8 | 1 | 0/0 | 0 | 1945 | 160 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.00 | 0.67 | 21.9 | 66.7 | 0 | 0/0 | 0 | 1957 | 168 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.85 | 98.93 | 0.5 | 19.0 | 58.2 | 2 | 0/0 | 0 | 1932 | 158 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-05 | |
| TestTime | Test Time | 09:50 | |
| TestDuration | Duration | 1:31:12 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
