Test Date: 2016-09-05 09:50
Analysis date: 2016-09-05 11:42
Analysis date: 2016-09-05 11:42
M2300 XRayHRQualification
Summary
| Module | Module | M2300 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.19 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.97 | 0.77 | 32.0 | 93.9 | 0 | 0/0 | 0 | 2029 | 163 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.21 | 0.71 | 33.8 | 100.2 | 0 | 0/0 | 0 | 2034 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.21 | 0.39 | 28.7 | 87.1 | 0 | 0/0 | 0 | 2000 | 164 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.14 | 0.81 | 54.7 | 158.1 | 0 | 0/0 | 0 | 2146 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.20 | 0.58 | 45.6 | 136.4 | 0 | 0/0 | 0 | 2115 | 148 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.31 | 0.62 | 68.2 | 195.6 | 0 | 0/0 | 0 | 2250 | 167 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.28 | 0.85 | 56.7 | 166.0 | 0 | 0/0 | 0 | 2169 | 153 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.84 | 99.27 | 1.1 | 67.3 | 196.3 | 0 | 0/0 | 0 | 2161 | 159 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.30 | 0.73 | 64.8 | 187.8 | 0 | 0/0 | 0 | 2200 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.85 | 99.24 | 0.75 | 58.7 | 169.5 | 0 | 0/0 | 0 | 2162 | 157 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.24 | 0.63 | 64.4 | 183.8 | 0 | 0/0 | 0 | 2231 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.24 | 0.94 | 52.1 | 151.3 | 0 | 0/0 | 0 | 2133 | 158 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.25 | 0.8 | 49.2 | 143.0 | 0 | 0/0 | 0 | 2114 | 167 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 98.95 | 0.6 | 30.3 | 91.4 | 0 | 0/0 | 0 | 2014 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.02 | 0.91 | 32.5 | 96.8 | 0 | 0/0 | 0 | 2007 | 168 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.24 | 0.85 | 32.2 | 94.8 | 0 | 0/0 | 0 | 2023 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-05 | |
| TestTime | Test Time | 09:50 | |
| TestDuration | Duration | 1:31:12 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
