Test Date: 2016-09-05 15:24
Analysis date: 2016-09-05 16:58
Analysis date: 2016-09-05 16:58
M2304 XRayHRQualification
Summary
| Module | Module | M2304 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.84 | 99.15 | 0.83 | 29.7 | 89.2 | 2 | 0/0 | 0 | 1976 | 163 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.27 | 0.57 | 33.5 | 100.8 | 0 | 0/0 | 0 | 2017 | 168 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.27 | 0.52 | 28.3 | 86.8 | 0 | 0/0 | 0 | 1973 | 156 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.25 | 0.66 | 50.5 | 148.0 | 0 | 0/0 | 0 | 2136 | 158 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.88 | 99.31 | 0.45 | 50.0 | 147.8 | 2 | 0/0 | 0 | 2128 | 154 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.86 | 99.31 | 0.59 | 66.2 | 192.2 | 1 | 0/0 | 0 | 2210 | 164 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.88 | 99.30 | 0.57 | 57.2 | 167.2 | 0 | 0/0 | 0 | 2123 | 160 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.31 | 0.68 | 59.8 | 175.1 | 0 | 0/0 | 0 | 2188 | 154 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.33 | 0.51 | 59.5 | 174.0 | 0 | 0/0 | 0 | 2173 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.27 | 0.47 | 59.1 | 174.2 | 0 | 0/0 | 0 | 2171 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.29 | 0.91 | 61.4 | 176.6 | 0 | 0/0 | 0 | 2182 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.24 | 0.91 | 49.4 | 145.4 | 0 | 0/0 | 0 | 2108 | 156 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.01 | 0.69 | 44.7 | 132.2 | 0 | 0/0 | 0 | 2074 | 156 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.29 | 0.53 | 27.8 | 84.9 | 0 | 0/0 | 0 | 1993 | 160 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.97 | 0.85 | 31.0 | 93.3 | 0 | 0/0 | 0 | 2000 | 161 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.19 | 0.58 | 31.2 | 92.5 | 0 | 0/0 | 0 | 1999 | 159 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-05 | |
| TestTime | Test Time | 15:24 | |
| TestDuration | Duration | 1:23:29 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
