Test Date: 2016-09-07 11:25
Analysis date: 2016-09-07 13:30
Analysis date: 2016-09-07 13:30
M2309 XRayHRQualification
Summary
| Module | Module | M2309 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 28 | |
| BumpBondingDefects | Bump Bonding Defects | 28 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.86 | 99.23 | 0.33 | 22.4 | 67.6 | 2 | 0/0 | 0 | 1949 | 166 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.88 | 99.25 | 0.53 | 23.8 | 72.4 | 1 | 0/0 | 0 | 1953 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.29 | 0.47 | 18.5 | 57.5 | 0 | 0/0 | 0 | 1922 | 156 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.88 | 99.28 | 0.34 | 37.1 | 109.8 | 2 | 0/0 | 0 | 2041 | 167 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.19 | 0.59 | 38.1 | 113.4 | 0 | 0/0 | 0 | 2059 | 167 | 0 |
|
Chip 5
|
A
|
2 | 0 | 99.85 | 99.25 | 0.8 | 47.1 | 136.8 | 2 | 0/0 | 0 | 2107 | 169 | 0 |
|
Chip 6
|
A
|
3 | 0 | 99.88 | 99.30 | 0.45 | 42.2 | 124.4 | 3 | 0/0 | 0 | 2079 | 163 | 0 |
|
Chip 7
|
A
|
4 | 0 | 99.88 | 99.31 | 0.44 | 41.3 | 122.4 | 4 | 0/0 | 0 | 2074 | 166 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.86 | 99.31 | 0.54 | 46.9 | 138.1 | 1 | 0/0 | 0 | 2113 | 162 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.86 | 99.29 | 0.43 | 42.8 | 126.5 | 2 | 0/0 | 0 | 2073 | 153 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.86 | 99.28 | 1.3 | 52.2 | 151.5 | 1 | 0/0 | 0 | 2135 | 163 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.30 | 0.58 | 41.7 | 123.2 | 1 | 0/0 | 0 | 2082 | 164 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.85 | 99.16 | 0.61 | 40.7 | 119.9 | 2 | 0/0 | 0 | 2092 | 168 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.27 | 0.5 | 22.3 | 68.4 | 1 | 0/0 | 0 | 1955 | 156 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.09 | 0.54 | 25.3 | 76.7 | 0 | 0/0 | 0 | 1972 | 168 | 0 |
|
Chip 15
|
A
|
6 | 0 | 99.87 | 99.21 | 0.6 | 26.0 | 77.3 | 6 | 0/0 | 0 | 1979 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-07 | |
| TestTime | Test Time | 11:25 | |
| TestDuration | Duration | 1:34:29 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
