Test Date: 2016-09-08 10:51
Analysis date: 2016-09-08 13:33
Analysis date: 2016-09-08 13:33
M2313 XRayHRQualification
Summary
| Module | Module | M2313 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.25 | % |
| Noise | Mean Noise | 157 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.29 | 0.47 | 30.0 | 90.4 | 0 | 0/0 | 0 | 2024 | 153 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.86 | 99.30 | 0.59 | 33.3 | 100.6 | 1 | 0/0 | 0 | 2046 | 160 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.23 | 0.49 | 30.5 | 93.5 | 0 | 0/0 | 0 | 2033 | 168 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.31 | 0.54 | 50.0 | 146.6 | 0 | 0/0 | 0 | 2153 | 155 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.14 | 5.04 | 55.5 | 163.1 | 0 | 0/0 | 0 | 2181 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.31 | 0.69 | 55.1 | 161.5 | 0 | 0/0 | 0 | 2180 | 152 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.27 | 0.69 | 53.6 | 158.3 | 0 | 0/0 | 0 | 2148 | 151 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.22 | 0.56 | 66.4 | 193.8 | 1 | 0/0 | 0 | 2244 | 160 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.29 | 0.51 | 58.7 | 171.6 | 0 | 0/0 | 0 | 2207 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.31 | 0.87 | 54.0 | 157.6 | 0 | 0/0 | 0 | 2170 | 153 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.33 | 0.77 | 65.8 | 189.5 | 0 | 0/0 | 0 | 2239 | 156 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.30 | 0.77 | 48.2 | 142.9 | 0 | 0/0 | 0 | 2164 | 154 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.23 | 0.55 | 44.0 | 131.8 | 0 | 0/0 | 0 | 2127 | 149 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.21 | 0.68 | 27.5 | 84.6 | 0 | 0/0 | 0 | 1999 | 153 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 98.98 | 0.67 | 31.4 | 95.4 | 0 | 0/0 | 0 | 2019 | 161 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.85 | 99.23 | 0.65 | 33.2 | 99.1 | 2 | 0/0 | 0 | 2028 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-08 | |
| TestTime | Test Time | 10:51 | |
| TestDuration | Duration | 1:26:17 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
