Test Date: 2016-09-19 15:21
Analysis date: 2016-09-19 17:31
Analysis date: 2016-09-19 17:31
M2316 XRayHRQualification
Summary
| Module | Module | M2316 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.22 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 98.96 | 0.64 | 26.2 | 79.2 | 0 | 0/0 | 0 | 1986 | 159 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 98.96 | 0.55 | 27.4 | 83.7 | 0 | 0/0 | 0 | 2005 | 161 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.24 | 0.43 | 24.2 | 74.4 | 0 | 0/0 | 0 | 1972 | 157 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.29 | 0.46 | 43.5 | 128.3 | 0 | 0/0 | 0 | 2110 | 157 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.29 | 0.67 | 42.4 | 126.8 | 0 | 0/0 | 0 | 2100 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.28 | 0.78 | 52.4 | 153.0 | 0 | 0/0 | 0 | 2158 | 149 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.35 | 0.58 | 53.7 | 156.8 | 0 | 0/0 | 0 | 2172 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.23 | 0.76 | 52.5 | 155.1 | 0 | 0/0 | 0 | 2162 | 157 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.32 | 0.39 | 63.7 | 185.7 | 0 | 0/0 | 0 | 2199 | 160 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.27 | 0.83 | 57.2 | 166.7 | 0 | 0/0 | 0 | 2159 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.65 | 55.6 | 162.7 | 0 | 0/0 | 0 | 2156 | 153 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.30 | 0.99 | 48.1 | 143.5 | 0 | 0/0 | 0 | 2139 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.29 | 0.63 | 45.9 | 137.1 | 0 | 0/0 | 0 | 2086 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.26 | 0.55 | 29.0 | 89.0 | 0 | 0/0 | 0 | 2004 | 173 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 98.92 | 0.87 | 29.4 | 89.3 | 0 | 0/0 | 0 | 2009 | 162 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 99.24 | 0.71 | 28.0 | 84.7 | 1 | 0/0 | 0 | 2003 | 158 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-19 | |
| TestTime | Test Time | 15:21 | |
| TestDuration | Duration | 1:29:50 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
