Test Date: 2016-09-19 17:13
Analysis date: 2016-09-19 18:57
Analysis date: 2016-09-19 18:57
M2321 XRayHRQualification
Summary
| Module | Module | M2321 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.19 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.86 | 99.24 | 0.65 | 28.7 | 85.7 | 2 | 0/0 | 0 | 1988 | 162 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.95 | 0.89 | 31.0 | 92.9 | 0 | 0/0 | 0 | 2015 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.26 | 0.35 | 28.6 | 87.0 | 0 | 0/0 | 0 | 1982 | 161 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.84 | 99.15 | 2.35 | 46.3 | 136.4 | 0 | 0/0 | 0 | 2106 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.28 | 0.56 | 46.9 | 139.2 | 0 | 0/0 | 0 | 2109 | 153 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.29 | 0.96 | 57.2 | 165.7 | 0 | 0/0 | 0 | 2174 | 155 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.29 | 0.82 | 55.5 | 162.0 | 0 | 0/0 | 0 | 2186 | 161 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.85 | 99.16 | 0.66 | 54.2 | 159.3 | 1 | 0/0 | 0 | 2157 | 153 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.34 | 0.43 | 50.8 | 150.9 | 0 | 0/0 | 0 | 2127 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.18 | 0.58 | 48.0 | 142.6 | 0 | 0/0 | 0 | 2099 | 149 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.16 | 0.86 | 65.0 | 189.5 | 0 | 0/0 | 0 | 2204 | 169 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.85 | 99.32 | 0.6 | 50.2 | 149.2 | 1 | 0/0 | 0 | 2127 | 168 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.84 | 99.23 | 0.98 | 47.1 | 139.9 | 1 | 0/0 | 0 | 2097 | 172 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.23 | 0.6 | 29.3 | 89.2 | 0 | 0/0 | 0 | 2003 | 175 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 98.97 | 0.8 | 30.1 | 90.7 | 0 | 0/0 | 0 | 2010 | 164 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.95 | 0.65 | 29.5 | 87.5 | 0 | 0/0 | 0 | 2008 | 162 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-19 | |
| TestTime | Test Time | 17:13 | |
| TestDuration | Duration | 1:29:9 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
