Test Date: 2016-09-19 17:13
Analysis date: 2016-09-19 19:00
Analysis date: 2016-09-19 19:00
M2322 XRayHRQualification
Summary
| Module | Module | M2322 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 21 | |
| BumpBondingDefects | Bump Bonding Defects | 19 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 156 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.87 | 99.27 | 0.38 | 27.8 | 83.0 | 2 | 0/0 | 0 | 2005 | 160 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 98.99 | 0.77 | 29.0 | 87.4 | 0 | 0/0 | 0 | 2007 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.29 | 0.38 | 22.9 | 71.5 | 0 | 0/0 | 0 | 1958 | 147 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.18 | 0.92 | 47.1 | 137.8 | 0 | 0/0 | 0 | 2138 | 159 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.25 | 0.74 | 48.6 | 143.0 | 0 | 0/0 | 0 | 2139 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.31 | 0.69 | 55.3 | 160.1 | 0 | 0/0 | 0 | 2155 | 150 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.26 | 0.67 | 58.0 | 167.9 | 0 | 0/0 | 0 | 2187 | 154 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.22 | 1.66 | 60.3 | 175.0 | 0 | 0/0 | 0 | 2195 | 155 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.31 | 0.71 | 56.5 | 166.5 | 0 | 0/0 | 0 | 2169 | 153 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.33 | 0.47 | 52.9 | 156.0 | 0 | 0/0 | 0 | 2150 | 155 | 0 |
|
Chip 10
|
A
|
4 | 0 | 99.87 | 99.24 | 1.42 | 53.6 | 157.2 | 3 | 0/0 | 0 | 2147 | 148 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.87 | 99.31 | 0.58 | 51.4 | 151.5 | 3 | 0/0 | 0 | 2152 | 161 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.30 | 1.01 | 43.4 | 128.9 | 1 | 0/0 | 0 | 2109 | 156 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.25 | 0.48 | 25.8 | 79.3 | 0 | 0/0 | 0 | 2000 | 154 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.20 | 0.57 | 29.2 | 88.2 | 1 | 0/0 | 0 | 2003 | 162 | 0 |
|
Chip 15
|
A
|
9 | 0 | 99.87 | 99.26 | 0.41 | 29.1 | 87.0 | 9 | 0/0 | 0 | 2004 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-19 | |
| TestTime | Test Time | 17:13 | |
| TestDuration | Duration | 1:29:9 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
