Test Date: 2016-09-27 09:42
Analysis date: 2016-09-27 11:21
Analysis date: 2016-09-27 11:21
M2328 XRayHRQualification
Summary
| Module | Module | M2328 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 5 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 98.99 | 0.64 | 28.9 | 87.5 | 0 | 0/0 | 0 | 2002 | 158 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.88 | 99.25 | 0.53 | 30.1 | 91.8 | 0 | 0/0 | 0 | 1973 | 159 | 1 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.26 | 0.42 | 29.3 | 89.6 | 0 | 0/0 | 0 | 2002 | 163 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.31 | 0.69 | 51.5 | 151.8 | 0 | 0/0 | 0 | 2140 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.31 | 0.5 | 51.1 | 151.5 | 0 | 0/0 | 0 | 2133 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.31 | 0.57 | 65.0 | 189.1 | 0 | 0/0 | 0 | 2218 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.29 | 0.66 | 54.4 | 161.0 | 0 | 0/0 | 0 | 2141 | 153 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.28 | 0.95 | 62.9 | 185.1 | 0 | 0/0 | 0 | 2202 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.30 | 0.62 | 60.7 | 177.6 | 0 | 0/0 | 0 | 2187 | 158 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.30 | 0.45 | 59.2 | 173.2 | 0 | 0/0 | 0 | 2170 | 159 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.28 | 1.28 | 63.0 | 182.1 | 0 | 0/0 | 0 | 2179 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.30 | 0.55 | 50.7 | 148.7 | 0 | 0/0 | 0 | 2140 | 157 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.33 | 0.7 | 50.3 | 148.4 | 0 | 0/0 | 0 | 2138 | 159 | 0 |
|
Chip 13
|
A
|
4 | 0 | 99.87 | 99.25 | 0.52 | 27.9 | 85.5 | 0 | 0/0 | 0 | 1847 | 161 | 4 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.22 | 1.21 | 30.8 | 93.3 | 0 | 0/0 | 0 | 2016 | 164 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.24 | 0.47 | 30.8 | 92.4 | 0 | 0/0 | 0 | 2013 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-27 | |
| TestTime | Test Time | 09:42 | |
| TestDuration | Duration | 1:16:47 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 18 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 2 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
