Test Date: 2016-09-26 10:58
Analysis date: 2016-09-26 13:35
Analysis date: 2016-09-26 13:35
M2330 XRayHRQualification
Summary
| Module | Module | M2330 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.25 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 98.92 | 0.99 | 27.7 | 82.9 | 1 | 0/0 | 0 | 1995 | 157 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.96 | 0.75 | 28.7 | 86.7 | 0 | 0/0 | 0 | 1981 | 160 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.30 | 0.36 | 24.2 | 74.9 | 0 | 0/0 | 0 | 1931 | 164 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.87 | 99.33 | 0.59 | 45.5 | 133.0 | 1 | 0/0 | 0 | 2103 | 156 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.30 | 0.84 | 48.9 | 144.1 | 0 | 0/0 | 0 | 2108 | 168 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.29 | 0.55 | 57.9 | 167.6 | 0 | 0/0 | 0 | 2172 | 161 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.30 | 0.62 | 56.0 | 164.1 | 1 | 0/0 | 0 | 2169 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.33 | 0.53 | 57.7 | 168.9 | 0 | 0/0 | 0 | 2179 | 156 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.30 | 0.65 | 60.0 | 174.7 | 1 | 0/0 | 0 | 2192 | 164 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.86 | 99.34 | 0.64 | 61.1 | 179.1 | 1 | 0/0 | 0 | 2211 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.35 | 0.68 | 58.7 | 170.1 | 0 | 0/0 | 0 | 2168 | 164 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.37 | 0.6 | 54.9 | 162.2 | 0 | 0/0 | 0 | 2201 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.28 | 0.63 | 45.2 | 133.2 | 0 | 0/0 | 0 | 2114 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.25 | 0.7 | 24.3 | 75.6 | 0 | 0/0 | 0 | 1972 | 152 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.18 | 5.64 | 29.9 | 90.3 | 0 | 0/0 | 0 | 2011 | 163 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.28 | 0.46 | 29.9 | 89.0 | 0 | 0/0 | 0 | 2004 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-26 | |
| TestTime | Test Time | 10:58 | |
| TestDuration | Duration | 1:16:48 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 6216 | |
| nWarnings | # Warnings | 9 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 2 | |
| channel_3_count | Channel 3 | 2453 | |
| message_tokenchain_count | Token Chain Length | 2446 | |
| message_readback_count | Readback start marker | 9 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
