Test Date: 2016-09-26 10:58
Analysis date: 2016-09-26 13:37
Analysis date: 2016-09-26 13:37
M2332 XRayHRQualification
Summary
| Module | Module | M2332 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.21 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.83 | 98.92 | 0.59 | 22.1 | 66.7 | 1 | 0/0 | 0 | 1943 | 161 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.87 | 99.27 | 0.54 | 24.3 | 73.5 | 2 | 0/0 | 0 | 1968 | 181 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.02 | 0.65 | 19.3 | 59.5 | 0 | 0/0 | 0 | 1919 | 162 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.86 | 99.32 | 0.64 | 35.6 | 105.8 | 0 | 0/0 | 0 | 1996 | 169 | 1 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 98.97 | 0.66 | 38.0 | 113.1 | 0 | 0/0 | 0 | 2040 | 172 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.28 | 0.67 | 41.5 | 122.3 | 0 | 0/0 | 0 | 2074 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.31 | 0.52 | 42.6 | 126.0 | 0 | 0/0 | 0 | 2071 | 171 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.30 | 0.7 | 44.3 | 131.3 | 0 | 0/0 | 0 | 2081 | 172 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.32 | 0.65 | 46.8 | 138.2 | 0 | 0/0 | 0 | 2106 | 170 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.29 | 0.52 | 45.2 | 133.1 | 0 | 0/0 | 0 | 2082 | 167 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.13 | 5.55 | 55.3 | 161.5 | 0 | 0/0 | 0 | 2167 | 187 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.33 | 0.47 | 44.8 | 132.3 | 0 | 0/0 | 0 | 2109 | 175 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.31 | 0.68 | 39.5 | 116.2 | 0 | 0/0 | 0 | 2042 | 173 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.29 | 0.43 | 23.8 | 72.3 | 0 | 0/0 | 0 | 1972 | 171 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.87 | 99.29 | 0.36 | 27.2 | 81.7 | 2 | 0/0 | 0 | 2000 | 171 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.84 | 98.99 | 0.55 | 25.8 | 76.8 | 1 | 0/0 | 0 | 1971 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-26 | |
| TestTime | Test Time | 10:58 | |
| TestDuration | Duration | 1:16:48 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
