Test Date: 2016-09-27 17:30
Analysis date: 2016-09-27 19:23
Analysis date: 2016-09-27 19:23
M2333 XRayHRQualification
Summary
| Module | Module | M2333 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.13 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.84 | 98.97 | 0.5 | 23.5 | 70.9 | 1 | 0/0 | 0 | 1951 | 169 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.24 | 0.46 | 24.7 | 74.8 | 0 | 0/0 | 0 | 1958 | 170 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 98.90 | 0.83 | 23.0 | 70.3 | 0 | 0/0 | 0 | 1961 | 171 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.09 | 0.77 | 37.5 | 110.8 | 0 | 0/0 | 0 | 2075 | 164 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.27 | 0.6 | 39.2 | 116.2 | 0 | 0/0 | 0 | 2051 | 165 | 1 |
|
Chip 5
|
A
|
1 | 0 | 99.86 | 99.24 | 0.68 | 49.9 | 145.1 | 1 | 0/0 | 0 | 2120 | 168 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.24 | 0.67 | 48.5 | 142.3 | 0 | 0/0 | 0 | 2133 | 173 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.87 | 99.27 | 0.47 | 48.3 | 141.4 | 2 | 0/0 | 0 | 2100 | 162 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 99.10 | 0.75 | 45.4 | 133.4 | 0 | 0/0 | 0 | 2102 | 171 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.27 | 0.57 | 43.7 | 129.6 | 0 | 0/0 | 0 | 2089 | 172 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.22 | 0.77 | 48.5 | 142.1 | 0 | 0/0 | 0 | 2124 | 183 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 98.96 | 0.75 | 39.9 | 118.8 | 0 | 0/0 | 0 | 2064 | 184 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.11 | 0.61 | 35.3 | 105.3 | 0 | 0/0 | 0 | 2040 | 181 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.30 | 0.43 | 19.6 | 60.7 | 0 | 0/0 | 0 | 1934 | 171 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.84 | 98.97 | 0.91 | 20.5 | 63.1 | 1 | 0/0 | 0 | 1953 | 170 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 98.95 | 0.44 | 18.7 | 57.7 | 1 | 0/0 | 0 | 1919 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-27 | |
| TestTime | Test Time | 17:30 | |
| TestDuration | Duration | 1:17:22 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
