Test Date: 2016-09-29 13:35
Analysis date: 2016-09-29 14:56
Analysis date: 2016-09-29 14:56
M2336 XRayHRQualification
Summary
| Module | Module | M2336 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 100 | |
| BumpBondingDefects | Bump Bonding Defects | 99 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.26 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.88 | 99.29 | 0.51 | 29.2 | 87.5 | 5 | 0/0 | 0 | 1979 | 170 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.29 | 0.47 | 31.4 | 94.7 | 1 | 0/0 | 0 | 2010 | 174 | 0 |
|
Chip 2
|
A
|
8 | 0 | 99.85 | 99.29 | 0.42 | 27.1 | 83.2 | 7 | 0/0 | 0 | 1923 | 168 | 1 |
|
Chip 3
|
A
|
9 | 0 | 99.86 | 99.22 | 0.73 | 48.7 | 142.3 | 9 | 0/0 | 0 | 2117 | 164 | 0 |
|
Chip 4
|
A
|
5 | 0 | 99.88 | 99.24 | 0.74 | 50.0 | 146.7 | 5 | 0/0 | 0 | 2146 | 169 | 0 |
|
Chip 5
|
A
|
2 | 0 | 99.84 | 99.31 | 0.95 | 62.2 | 179.1 | 2 | 0/0 | 0 | 2213 | 167 | 0 |
|
Chip 6
|
A
|
5 | 0 | 99.87 | 99.30 | 0.9 | 57.4 | 167.7 | 5 | 0/0 | 0 | 2179 | 170 | 0 |
|
Chip 7
|
A
|
9 | 0 | 99.88 | 99.32 | 0.53 | 64.2 | 186.7 | 9 | 0/0 | 0 | 2218 | 170 | 0 |
|
Chip 8
|
A
|
13 | 0 | 99.87 | 99.29 | 0.8 | 55.4 | 163.0 | 13 | 0/0 | 0 | 2147 | 160 | 0 |
|
Chip 9
|
A
|
8 | 0 | 99.86 | 99.27 | 0.78 | 56.4 | 164.9 | 8 | 0/0 | 0 | 2147 | 165 | 0 |
|
Chip 10
|
A
|
8 | 0 | 99.87 | 99.31 | 0.68 | 65.4 | 190.1 | 8 | 0/0 | 0 | 2202 | 179 | 0 |
|
Chip 11
|
A
|
10 | 0 | 99.87 | 99.33 | 0.72 | 53.0 | 156.6 | 10 | 0/0 | 0 | 2157 | 180 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.32 | 0.55 | 48.7 | 142.9 | 1 | 0/0 | 0 | 2142 | 166 | 0 |
|
Chip 13
|
A
|
6 | 0 | 99.86 | 99.28 | 0.47 | 27.8 | 85.1 | 6 | 0/0 | 0 | 1983 | 163 | 0 |
|
Chip 14
|
A
|
6 | 0 | 99.84 | 99.02 | 0.65 | 30.3 | 91.7 | 6 | 0/0 | 0 | 2009 | 165 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.83 | 99.09 | 1.0 | 31.4 | 93.7 | 4 | 0/0 | 0 | 1995 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-29 | |
| TestTime | Test Time | 13:35 | |
| TestDuration | Duration | 1:8:58 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 25 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 2 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
