Test Date: 2016-10-05 12:02
Analysis date: 2016-10-05 13:34
Analysis date: 2016-10-05 13:34
M2348 XRayHRQualification
Summary
| Module | Module | M2348 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 11 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 8 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.21 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.87 | 99.26 | 0.37 | 23.9 | 71.8 | 3 | 0/0 | 0 | 1979 | 160 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.22 | 0.72 | 24.2 | 73.6 | 0 | 0/0 | 0 | 1976 | 163 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.26 | 0.37 | 23.1 | 70.4 | 0 | 0/0 | 0 | 1958 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.26 | 0.53 | 42.0 | 124.0 | 0 | 0/0 | 0 | 2089 | 164 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.85 | 99.06 | 0.54 | 42.5 | 125.7 | 0 | 0/0 | 0 | 2030 | 165 | 2 |
|
Chip 5
|
A
|
4 | 0 | 99.87 | 99.06 | 0.74 | 42.2 | 124.8 | 0 | 0/0 | 0 | 1933 | 156 | 4 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.27 | 0.57 | 42.5 | 125.3 | 0 | 0/0 | 0 | 2108 | 158 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.32 | 0.62 | 50.1 | 145.4 | 0 | 0/0 | 0 | 2144 | 157 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.32 | 0.39 | 44.6 | 131.5 | 0 | 0/0 | 0 | 2097 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.25 | 0.47 | 40.9 | 121.2 | 0 | 0/0 | 0 | 2070 | 164 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.88 | 99.35 | 0.41 | 40.9 | 120.3 | 0 | 0/0 | 0 | 1984 | 156 | 2 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.26 | 1.0 | 35.2 | 105.4 | 0 | 0/0 | 0 | 2043 | 158 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.23 | 1.06 | 35.3 | 105.5 | 0 | 0/0 | 0 | 2053 | 164 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 98.99 | 0.39 | 17.7 | 55.5 | 0 | 0/0 | 0 | 1917 | 148 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.12 | 0.47 | 20.7 | 63.7 | 0 | 0/0 | 0 | 1948 | 155 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.21 | 0.39 | 20.3 | 61.9 | 0 | 0/0 | 0 | 1926 | 153 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-05 | |
| TestTime | Test Time | 12:02 | |
| TestDuration | Duration | 1:16:25 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
