Test Date: 2016-10-05 12:02
Analysis date: 2016-10-05 13:37
Analysis date: 2016-10-05 13:37
M2349 XRayHRQualification
Summary
| Module | Module | M2349 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 20 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.21 | % |
| Noise | Mean Noise | 156 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.23 | 0.54 | 28.9 | 86.9 | 0 | 0/0 | 0 | 1985 | 159 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.89 | 0.84 | 30.8 | 92.6 | 0 | 0/0 | 0 | 2010 | 157 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.02 | 0.99 | 30.8 | 93.0 | 1 | 0/0 | 0 | 1998 | 166 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.85 | 99.12 | 1.13 | 53.4 | 155.1 | 1 | 0/0 | 0 | 2174 | 165 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.90 | 99.28 | 0.7 | 47.5 | 139.6 | 2 | 0/0 | 0 | 2124 | 152 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.85 | 99.24 | 0.7 | 59.9 | 172.8 | 1 | 0/0 | 0 | 2157 | 152 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.32 | 0.59 | 60.5 | 175.4 | 0 | 0/0 | 0 | 2192 | 150 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.32 | 0.63 | 59.3 | 170.5 | 0 | 0/0 | 0 | 2192 | 152 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.86 | 99.29 | 0.8 | 60.0 | 173.8 | 3 | 0/0 | 0 | 2171 | 149 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.36 | 0.54 | 58.2 | 169.0 | 0 | 0/0 | 0 | 2189 | 156 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.89 | 99.34 | 0.48 | 52.3 | 153.2 | 1 | 0/0 | 0 | 2133 | 149 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.30 | 0.68 | 53.2 | 156.2 | 0 | 0/0 | 0 | 2157 | 161 | 0 |
|
Chip 12
|
A
|
3 | 0 | 99.88 | 99.34 | 0.65 | 44.9 | 132.0 | 3 | 0/0 | 0 | 2090 | 153 | 0 |
|
Chip 13
|
A
|
6 | 0 | 99.85 | 99.11 | 0.67 | 29.4 | 89.1 | 2 | 0/0 | 0 | 1867 | 165 | 4 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.31 | 0.57 | 30.4 | 91.6 | 0 | 0/0 | 0 | 2008 | 153 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.84 | 98.97 | 0.73 | 29.2 | 87.0 | 2 | 0/0 | 0 | 2004 | 160 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-05 | |
| TestTime | Test Time | 12:02 | |
| TestDuration | Duration | 1:16:25 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 18 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 1 | |
| message_tokenchain_count | Token Chain Length | 2 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
