Test Date: 2016-10-05 12:02
Analysis date: 2016-10-05 13:39
Analysis date: 2016-10-05 13:39
M2350 XRayHRQualification
Summary
| Module | Module | M2350 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.22 | 0.87 | 29.9 | 88.9 | 0 | 0/0 | 0 | 1992 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.01 | 0.73 | 30.3 | 91.8 | 0 | 0/0 | 0 | 1994 | 166 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.20 | 0.88 | 24.4 | 75.7 | 0 | 0/0 | 0 | 1957 | 159 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.27 | 0.73 | 48.5 | 141.6 | 0 | 0/0 | 0 | 2129 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.34 | 0.56 | 46.8 | 137.9 | 0 | 0/0 | 0 | 2118 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.26 | 0.83 | 63.2 | 183.4 | 0 | 0/0 | 0 | 2217 | 159 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.29 | 0.82 | 49.6 | 147.8 | 0 | 0/0 | 0 | 2102 | 154 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.88 | 99.26 | 0.75 | 56.8 | 166.2 | 1 | 0/0 | 0 | 2161 | 164 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.87 | 99.29 | 0.45 | 63.8 | 186.0 | 2 | 0/0 | 0 | 2177 | 169 | 1 |
|
Chip 9
|
A
|
2 | 0 | 99.87 | 99.32 | 0.57 | 60.9 | 177.8 | 2 | 0/0 | 0 | 2168 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.31 | 0.71 | 64.8 | 187.6 | 0 | 0/0 | 0 | 2209 | 165 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.22 | 0.76 | 54.9 | 160.8 | 0 | 0/0 | 0 | 2185 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.27 | 0.62 | 50.2 | 147.8 | 0 | 0/0 | 0 | 2127 | 167 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.23 | 0.54 | 29.7 | 90.6 | 0 | 0/0 | 0 | 2004 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.00 | 0.68 | 32.1 | 96.6 | 0 | 0/0 | 0 | 2042 | 174 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 99.19 | 0.76 | 30.8 | 91.7 | 1 | 0/0 | 0 | 2015 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-05 | |
| TestTime | Test Time | 12:02 | |
| TestDuration | Duration | 1:16:25 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 2 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
