Test Date: 2016-10-10 09:55
Analysis date: 2016-10-10 11:26
Analysis date: 2016-10-10 11:26
M2352 XRayHRQualification
Summary
| Module | Module | M2352 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 23 | |
| BumpBondingDefects | Bump Bonding Defects | 21 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.22 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.87 | 99.25 | 0.46 | 25.2 | 75.1 | 1 | 0/0 | 0 | 1976 | 162 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.26 | 0.4 | 24.9 | 74.8 | 0 | 0/0 | 0 | 1984 | 156 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.08 | 0.44 | 21.9 | 66.9 | 0 | 0/0 | 0 | 1961 | 157 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.27 | 0.41 | 37.4 | 110.0 | 0 | 0/0 | 0 | 2048 | 153 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.30 | 0.67 | 38.6 | 114.5 | 0 | 0/0 | 0 | 2071 | 157 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.31 | 0.42 | 49.4 | 144.0 | 0 | 0/0 | 0 | 2177 | 159 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.85 | 99.21 | 0.66 | 45.2 | 132.8 | 1 | 0/0 | 0 | 2118 | 157 | 0 |
|
Chip 7
|
A
|
7 | 0 | 99.87 | 99.29 | 0.81 | 44.6 | 131.4 | 7 | 0/0 | 0 | 2108 | 155 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.31 | 0.4 | 42.4 | 125.3 | 0 | 0/0 | 0 | 2121 | 154 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.84 | 99.01 | 0.53 | 41.6 | 123.0 | 2 | 0/0 | 0 | 2103 | 164 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.31 | 0.45 | 39.4 | 116.5 | 1 | 0/0 | 0 | 2074 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.23 | 0.51 | 35.2 | 105.4 | 0 | 0/0 | 0 | 2046 | 165 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.30 | 0.56 | 34.9 | 104.2 | 0 | 0/0 | 0 | 2039 | 166 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.87 | 99.28 | 0.35 | 21.1 | 64.5 | 1 | 0/0 | 0 | 1890 | 166 | 2 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 98.92 | 0.49 | 23.1 | 69.2 | 0 | 0/0 | 0 | 1949 | 159 | 0 |
|
Chip 15
|
A
|
8 | 0 | 99.87 | 99.27 | 0.4 | 23.8 | 70.8 | 8 | 0/0 | 0 | 1958 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-10 | |
| TestTime | Test Time | 09:55 | |
| TestDuration | Duration | 1:16:51 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
