Test Date: 2016-10-11 09:45
Analysis date: 2016-10-11 12:12
Analysis date: 2016-10-11 12:12
M2357 XRayHRQualification
Summary
| Module | Module | M2357 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.19 | % |
| Noise | Mean Noise | 156 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.03 | 0.67 | 26.5 | 80.6 | 0 | 0/0 | 0 | 1957 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.14 | 0.48 | 28.6 | 87.7 | 0 | 0/0 | 0 | 1993 | 165 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 98.94 | 0.6 | 23.3 | 73.1 | 0 | 0/0 | 0 | 1943 | 153 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.27 | 0.49 | 42.0 | 124.7 | 0 | 0/0 | 0 | 2071 | 153 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 98.97 | 0.69 | 48.7 | 144.8 | 0 | 0/0 | 0 | 2112 | 159 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.29 | 0.71 | 57.6 | 167.4 | 0 | 0/0 | 0 | 2168 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.28 | 0.87 | 52.3 | 153.3 | 0 | 0/0 | 0 | 2126 | 153 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.27 | 0.78 | 58.1 | 169.8 | 1 | 0/0 | 0 | 2167 | 155 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.25 | 0.66 | 63.7 | 186.6 | 0 | 0/0 | 0 | 2189 | 161 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.25 | 0.99 | 54.4 | 159.0 | 0 | 0/0 | 0 | 2124 | 162 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.28 | 0.61 | 51.6 | 150.9 | 0 | 0/0 | 0 | 2130 | 149 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.29 | 0.56 | 48.6 | 143.4 | 0 | 0/0 | 0 | 2129 | 157 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.26 | 0.47 | 44.2 | 131.0 | 0 | 0/0 | 0 | 2092 | 160 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.00 | 0.55 | 22.2 | 70.0 | 0 | 0/0 | 0 | 1954 | 148 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.26 | 0.3 | 26.3 | 81.1 | 0 | 0/0 | 0 | 1968 | 157 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.18 | 0.55 | 24.0 | 73.9 | 0 | 0/0 | 0 | 1943 | 152 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-11 | |
| TestTime | Test Time | 09:45 | |
| TestDuration | Duration | 1:16:51 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 18 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 2 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 1 |
