Test Date: 2015-09-15 16:10
Analysis date: 2015-12-09 17:45
Analysis date: 2015-12-09 17:45
M4078 XRayHRQualification
Summary
| Module | Module | M4078 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 10/6/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.81/98.49 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
1 | 0 | 99.82 | 97.70 | 26.93 | 117.4 | 1 | 30.5 | 0/0 | 0 | 2084 | 170 | 0 |
|
Chip 1
|
B
|
0 | 0 | 100.08 | 97.66 | 14.76 | 125.5 | 0 | 32.6 | 0/0 | 0 | 2071 | 179 | 0 |
|
Chip 2
|
B
|
0 | 0 | 98.95 | 97.32 | 94.88 | 109.6 | 0 | 28.4 | 0/0 | 0 | 2015 | 178 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.95 | 98.67 | 9.90 | 175.6 | 0 | 45.7 | 0/0 | 0 | 2172 | 171 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.95 | 98.83 | 9.17 | 175.0 | 0 | 45.7 | 0/0 | 0 | 2139 | 157 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.87 | 99.24 | 0.60 | 198.3 | 1 | 51.8 | 0/0 | 0 | 2192 | 163 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.91 | 99.18 | 8.68 | 182.2 | 0 | 47.6 | 0/0 | 0 | 2159 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 98.98 | 0.94 | 187.5 | 0 | 49.0 | 0/0 | 0 | 2206 | 160 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.20 | 0.88 | 184.4 | 0 | 48.2 | 0/0 | 0 | 2157 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.24 | 0.46 | 179.8 | 0 | 47.1 | 0/0 | 0 | 2142 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.24 | 0.71 | 196.2 | 0 | 51.3 | 0/0 | 0 | 2198 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 100.02 | 98.85 | 13.86 | 177.6 | 0 | 46.5 | 0/0 | 0 | 2143 | 167 | 0 |
|
Chip 12
|
A
|
0 | 0 | 100.00 | 98.78 | 12.31 | 167.2 | 0 | 43.6 | 0/0 | 0 | 2127 | 158 | 0 |
|
Chip 13
|
B
|
1 | 0 | 99.17 | 97.30 | 82.98 | 115.1 | 1 | 29.9 | 0/0 | 0 | 2022 | 183 | 0 |
|
Chip 14
|
B
|
0 | 0 | 99.97 | 97.98 | 20.13 | 123.3 | 0 | 32.1 | 0/0 | 0 | 2025 | 166 | 0 |
|
Chip 15
|
B
|
1 | 0 | 99.84 | 97.64 | 26.06 | 121.5 | 1 | 31.6 | 0/0 | 0 | 2056 | 176 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
