Test Date: 2016-11-08 14:08
Analysis date: 2016-11-08 15:13
M1003 XRayHRQualification
Chips

Overview

Summary
Module Module M1003
Grade Grade A
ManualGrade Manual Grade None
ROCGrades ROC Grades A/B/C 16/0/0
PixelDefects Total Pixel Defects 60
BumpBondingDefects Bump Bonding Defects 24
NoisyPixels Noisy Pixels 0
HotPixelDefects Hot Pixels 36
ROCsWithReadoutProblems ROCs with r/o problems 0
ROCsWithUniformityProblems ROCs with unif problems 0
Efficiency Efficiency 150/300 99.81/99.55 %
Noise Mean Noise 367 e-
Summary ROCs
ROC Grade Def DC Eff 150 Eff 300 Eff chi2 Rate "300" BB def Rate "100" R/O Unif. Thr [e-] "250" Noise "250" Noisy pix
Chip 0
A
 2 0 99.79 99.52 0.33 206.5 2 69.1 0/0 0 3790 349 1050
Chip 1
A
 0 0 99.82 99.52 0.2 201.6 0 67.5 0/0 0 3637 364 1259
Chip 2
A
 1 0 99.81 99.58 0.35 187.9 1 62.0 0/0 0 3770 346 997
Chip 3
A
 6 0 99.82 99.53 0.32 173.3 7 57.6 0/0 0 3768 347 1080
Chip 4
A
 0 0 99.79 99.65 0.2 165.2 0 54.8 0/0 0 3793 339 916
Chip 5
A
 0 0 99.81 99.48 0.24 251.7 0 83.1 0/0 0 3679 389 1632
Chip 6
A
 0 0 99.78 99.50 0.71 233.2 0 78.3 0/0 0 3756 375 1434
Chip 7
A
 0 0 99.81 99.58 0.3 271.9 0 90.6 0/0 0 3795 408 1853
Chip 8
A
 0 0 99.82 99.56 0.35 309.8 0 102.2 0/0 0 3611 394 1741
Chip 9
A
 0 0 99.81 99.55 0.37 323.3 0 106.4 0/0 0 3639 420 2066
Chip 10
A
 36 0 99.81 99.52 0.29 284.5 0 94.6 0/0 0 3846 356 1222
Chip 11
A
 3 0 99.82 99.60 0.29 181.3 5 60.3 0/0 0 3793 325 739
Chip 12
A
 5 0 99.81 99.51 0.23 186.1 8 62.5 0/0 0 3715 370 1359
Chip 13
A
 2 0 99.79 99.54 0.35 247.3 3 80.9 0/0 0 3630 387 1591
Chip 14
A
 3 0 99.83 99.53 0.27 210.6 4 69.8 0/0 0 3837 317 655
Chip 15
A
 2 0 99.83 99.59 0.27 252.5 2 83.2 0/0 0 3631 386 1557
Efficiency at 150 MHz/cm2
Efficiency at 300 MHz/cm2
BB defects 300
BB defects 100
Noise 250
Hit Map 300
Hits distribution 300 inner/edge/corner
Hit Map 100
Hits distribution 100 inner/edge/corner
Bump Bonding Defects 300
BB defects 300
Bump Bonding Defects 100
BB defects 100
Masked Hot Pixels 300
Hot pixels 300
Masked Hot Pixels 100
Hot pixels 100
Threshold 250
Threshold distribution 250
Noise 250
Noise distribution 250
Pixel Alive Map
Dead/inefficient pixels
HR Efficiency Map 50
Efficiency distribution 50
HR Efficiency Map 100
Efficiency distribution 100
HR Efficiency Map 150
Efficiency distribution 150
HR Efficiency Map 200
Efficiency distribution 200
HR Efficiency Map 250
Efficiency distribution 250
HR Efficiency Map 300
Efficiency distribution 300
Retrimmed Hot Pixels 50
Retri Hot Pix 50
Retrimmed Hot Pixels 150
Retri Hot Pix 150
Setup
TestCenter Test Center ETHZ
TestDate Test Date 2016-11-08
TestTime Test Time 14:08
TestDuration Duration 0:59:31
pXar pXar version v2.7.6+59~gd48421b
DTB_FW DTB FW 4.7
Errors
nCriticals # Criticals 0
nErrors # Errors 13
nWarnings # Warnings 0
channel_0_count Channel 0 0
channel_1_count Channel 1 0
channel_2_count Channel 2 0
channel_3_count Channel 3 0
