Test Date: 2016-10-24 17:03
Analysis date: 2016-10-24 20:37
Analysis date: 2016-10-24 20:37
M1012 XRayHRQualification
Summary
| Module | Module | M1012 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 162 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.80/99.52 | % |
| Noise | Mean Noise | 315 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.82 | 99.51 | 0.21 | 51.7 | 160.0 | 2 | 0/0 | 0 | 3864 | 302 | 410 |
|
Chip 1
|
A
|
0 | 0 | 99.78 | 99.58 | 0.27 | 61.0 | 188.4 | 0 | 0/0 | 0 | 3804 | 336 | 877 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 99.46 | 0.43 | 61.8 | 190.9 | 0 | 0/0 | 0 | 3807 | 315 | 595 |
|
Chip 3
|
A
|
1 | 0 | 99.77 | 99.40 | 0.46 | 47.5 | 144.8 | 0 | 0/0 | 0 | 3842 | 315 | 578 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.62 | 0.18 | 44.6 | 136.3 | 0 | 0/0 | 0 | 3898 | 299 | 422 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.51 | 0.33 | 71.0 | 219.9 | 0 | 0/0 | 0 | 3784 | 337 | 909 |
|
Chip 6
|
A
|
0 | 0 | 99.80 | 99.48 | 0.45 | 70.0 | 213.6 | 0 | 0/0 | 0 | 3793 | 330 | 765 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.52 | 0.26 | 64.3 | 198.1 | 0 | 0/0 | 0 | 3819 | 328 | 765 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 99.55 | 0.29 | 61.1 | 192.1 | 0 | 0/0 | 0 | 3869 | 312 | 560 |
|
Chip 9
|
A
|
0 | 0 | 99.78 | 99.48 | 0.42 | 65.1 | 202.5 | 0 | 0/0 | 0 | 3826 | 311 | 551 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.51 | 0.34 | 74.5 | 229.6 | 0 | 0/0 | 0 | 3772 | 311 | 536 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.55 | 0.24 | 52.4 | 162.6 | 0 | 0/0 | 0 | 3838 | 320 | 644 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.50 | 0.28 | 46.6 | 143.4 | 0 | 0/0 | 0 | 3856 | 315 | 571 |
|
Chip 13
|
C
|
158 | # | 99.78 | 99.50 | 0.36 | 60.3 | 185.7 | 6 | 0/0 | 2+3/19 | 3714 | 313 | 551 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.57 | 0.42 | 58.5 | 181.9 | 0 | 0/0 | 0 | 3824 | 297 | 382 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.62 | 0.19 | 60.0 | 189.3 | 0 | 0/0 | 0 | 3776 | 300 | 417 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-24 | |
| TestTime | Test Time | 17:03 | |
| TestDuration | Duration | 1:0:2 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 38696 | |
| nWarnings | # Warnings | 69035 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 37835 | |
| message_tokenchain_count | Token Chain Length | 46 | |
| message_readback_count | Readback start marker | 18917 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
