Test Date: 2016-10-25 08:21
Analysis date: 2016-10-25 09:24
Analysis date: 2016-10-25 09:24
M1016 XRayHRQualification
Summary
| Module | Module | M1016 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.54 | % |
| Noise | Mean Noise | 334 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.49 | 0.29 | 65.5 | 203.6 | 0 | 0/0 | 0 | 3816 | 329 | 787 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.56 | 0.33 | 71.4 | 222.3 | 0 | 0/0 | 0 | 3721 | 364 | 1273 |
|
Chip 2
|
A
|
1 | 0 | 99.81 | 99.54 | 0.28 | 71.4 | 222.3 | 0 | 0/0 | 0 | 3624 | 348 | 1037 |
|
Chip 3
|
A
|
0 | 0 | 99.80 | 99.57 | 0.29 | 49.4 | 150.4 | 0 | 0/0 | 0 | 3864 | 304 | 476 |
|
Chip 4
|
A
|
0 | 0 | 99.80 | 99.51 | 0.28 | 50.7 | 153.9 | 0 | 0/0 | 0 | 3857 | 299 | 404 |
|
Chip 5
|
A
|
0 | 0 | 99.80 | 99.51 | 0.52 | 85.1 | 265.9 | 0 | 0/0 | 0 | 3708 | 372 | 1437 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.56 | 0.26 | 71.6 | 220.9 | 0 | 0/0 | 0 | 3755 | 354 | 1073 |
|
Chip 7
|
A
|
1 | 0 | 99.80 | 99.56 | 0.41 | 80.6 | 246.8 | 1 | 0/0 | 0 | 3829 | 341 | 1014 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.53 | 0.42 | 75.4 | 234.7 | 0 | 0/0 | 0 | 3810 | 338 | 915 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.48 | 0.31 | 68.9 | 213.0 | 0 | 0/0 | 0 | 3793 | 339 | 930 |
|
Chip 10
|
A
|
0 | 0 | 99.78 | 99.49 | 0.34 | 78.4 | 241.1 | 0 | 0/0 | 0 | 3488 | 336 | 947 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.58 | 0.27 | 48.6 | 149.7 | 0 | 0/0 | 0 | 3831 | 310 | 569 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.58 | 0.18 | 53.2 | 162.7 | 0 | 0/0 | 0 | 3818 | 351 | 1068 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.58 | 0.27 | 56.4 | 174.0 | 0 | 0/0 | 0 | 3568 | 318 | 659 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.56 | 0.21 | 56.3 | 177.1 | 0 | 0/0 | 0 | 3806 | 321 | 639 |
|
Chip 15
|
A
|
0 | 0 | 99.80 | 99.55 | 0.26 | 52.2 | 163.8 | 0 | 0/0 | 0 | 3819 | 314 | 567 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 08:21 | |
| TestDuration | Duration | 0:57:22 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1579 | |
| nWarnings | # Warnings | 206563 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1440 | |
| message_tokenchain_count | Token Chain Length | 109 | |
| message_readback_count | Readback start marker | 19 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
