Test Date: 2016-10-25 09:48
Analysis date: 2016-10-25 11:20
Analysis date: 2016-10-25 11:20
M1019 XRayHRQualification
Summary
| Module | Module | M1019 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.59 | % |
| Noise | Mean Noise | 342 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.55 | 0.53 | 70.6 | 208.6 | 0 | 0/0 | 0 | 3513 | 366 | 1313 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.47 | 0.62 | 83.2 | 244.8 | 0 | 0/0 | 0 | 3502 | 389 | 1636 |
|
Chip 2
|
A
|
2 | 0 | 99.81 | 99.56 | 0.3 | 74.8 | 217.8 | 3 | 0/0 | 0 | 3780 | 335 | 895 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.57 | 0.35 | 56.5 | 167.4 | 0 | 0/0 | 0 | 3859 | 308 | 540 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.56 | 0.2 | 53.9 | 161.3 | 0 | 0/0 | 0 | 3651 | 307 | 516 |
|
Chip 5
|
A
|
0 | 0 | 99.79 | 99.52 | 0.25 | 81.8 | 247.7 | 0 | 0/0 | 0 | 3834 | 337 | 938 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.81 | 0.26 | 81.9 | 243.7 | 0 | 0/0 | 0 | 3864 | 326 | 750 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.63 | 0.18 | 110.7 | 331.4 | 0 | 0/0 | 0 | 3746 | 376 | 1447 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.73 | 0.19 | 93.2 | 284.6 | 0 | 0/0 | 0 | 3899 | 324 | 704 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.51 | 0.2 | 93.2 | 285.1 | 0 | 0/0 | 0 | 3772 | 357 | 1179 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.59 | 0.25 | 88.0 | 264.4 | 0 | 0/0 | 0 | 3821 | 336 | 856 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.71 | 0.24 | 56.3 | 169.1 | 0 | 0/0 | 0 | 3850 | 304 | 497 |
|
Chip 12
|
A
|
0 | 0 | 99.79 | 99.48 | 0.29 | 56.7 | 172.2 | 0 | 0/0 | 0 | 3818 | 312 | 603 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.56 | 0.32 | 84.2 | 253.4 | 0 | 0/0 | 0 | 3768 | 350 | 1105 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.60 | 0.3 | 74.1 | 217.2 | 0 | 0/0 | 0 | 3525 | 359 | 1225 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.32 | 84.3 | 258.6 | 0 | 0/0 | 0 | 3736 | 385 | 1601 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-25 | |
| TestTime | Test Time | 09:48 | |
| TestDuration | Duration | 1:0:13 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 71 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 3 | |
| message_readback_count | Readback start marker | 6 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
