Test Date: 2016-11-17 10:22
Analysis date: 2016-11-17 11:36
Analysis date: 2016-11-17 11:36
M1020 XRayHRQualification
Summary
| Module | Module | M1020 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 330 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.59 | 0.33 | 75.0 | 228.7 | 0 | 0/0 | 0 | 3725 | 337 | 929 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.64 | 0.24 | 57.2 | 174.3 | 0 | 0/0 | 0 | 3814 | 307 | 529 |
|
Chip 2
|
A
|
2 | 0 | 99.80 | 99.56 | 0.42 | 70.7 | 214.5 | 0 | 0/0 | 0 | 3739 | 330 | 831 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.61 | 0.32 | 55.4 | 168.8 | 0 | 0/0 | 0 | 3611 | 310 | 560 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.58 | 0.24 | 52.8 | 159.7 | 0 | 0/0 | 0 | 3810 | 322 | 648 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.55 | 0.31 | 66.6 | 204.3 | 0 | 0/0 | 0 | 3795 | 325 | 734 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.48 | 0.45 | 82.6 | 256.5 | 0 | 0/0 | 0 | 4089 | 366 | 1414 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.55 | 0.4 | 96.9 | 297.2 | 0 | 0/0 | 0 | 3699 | 397 | 1759 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.64 | 0.28 | 67.7 | 209.9 | 0 | 0/0 | 0 | 3553 | 330 | 811 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.52 | 0.27 | 58.9 | 181.4 | 0 | 0/0 | 0 | 3792 | 313 | 574 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.58 | 0.33 | 79.2 | 246.7 | 0 | 0/0 | 0 | 3764 | 353 | 1127 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.56 | 0.29 | 56.1 | 171.8 | 0 | 0/0 | 0 | 3805 | 317 | 658 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.50 | 0.24 | 39.4 | 120.6 | 0 | 0/0 | 0 | 3850 | 289 | 373 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.56 | 0.35 | 69.8 | 215.4 | 0 | 0/0 | 0 | 3700 | 360 | 1223 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.57 | 0.33 | 64.7 | 198.2 | 0 | 0/0 | 0 | 3822 | 321 | 732 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.59 | 0.29 | 62.3 | 192.1 | 0 | 0/0 | 0 | 3636 | 311 | 589 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-17 | |
| TestTime | Test Time | 10:22 | |
| TestDuration | Duration | 0:58:32 | |
| pXar | pXar version | v2.7.6+72~gcee0f0f | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 17 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 3 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 2 |
