Test Date: 2016-10-26 14:26
Analysis date: 2016-10-26 15:44
Analysis date: 2016-10-26 15:44
M1041 XRayHRQualification
Summary
| Module | Module | M1041 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.54 | % |
| Noise | Mean Noise | 316 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.83 | 99.50 | 0.27 | 55.1 | 172.7 | 1 | 0/0 | 0 | 3812 | 309 | 539 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.62 | 0.27 | 54.8 | 170.2 | 0 | 0/0 | 0 | 3837 | 292 | 324 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.56 | 0.31 | 66.1 | 206.2 | 0 | 0/0 | 0 | 3800 | 330 | 828 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 99.60 | 0.17 | 44.8 | 135.6 | 1 | 0/0 | 0 | 3855 | 297 | 405 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.58 | 0.21 | 36.5 | 110.9 | 0 | 0/0 | 0 | 3927 | 277 | 259 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.62 | 0.26 | 53.2 | 164.6 | 0 | 0/0 | 0 | 3782 | 334 | 797 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.50 | 0.26 | 46.5 | 142.5 | 0 | 0/0 | 0 | 3873 | 293 | 338 |
|
Chip 7
|
A
|
2 | 0 | 99.81 | 99.53 | 0.32 | 47.0 | 144.2 | 2 | 0/0 | 0 | 3613 | 315 | 581 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.28 | 0.17 | 41.2 | 126.1 | 0 | 0/0 | 0 | 3828 | 310 | 525 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 99.44 | 0.21 | 48.6 | 148.6 | 0 | 0/0 | 0 | 3826 | 327 | 790 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.59 | 0.28 | 59.3 | 184.0 | 0 | 0/0 | 0 | 3777 | 355 | 1153 |
|
Chip 11
|
A
|
1 | 0 | 99.81 | 99.52 | 0.2 | 37.5 | 112.7 | 1 | 0/0 | 0 | 3829 | 284 | 254 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.61 | 0.22 | 45.5 | 138.4 | 0 | 0/0 | 0 | 3834 | 313 | 589 |
|
Chip 13
|
A
|
4 | 0 | 99.83 | 99.56 | 0.19 | 65.2 | 199.3 | 0 | 0/0 | 0 | 3755 | 340 | 917 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.61 | 0.25 | 58.7 | 182.6 | 0 | 0/0 | 0 | 3836 | 319 | 678 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.54 | 0.35 | 79.0 | 244.9 | 0 | 0/0 | 0 | 3765 | 361 | 1221 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-26 | |
| TestTime | Test Time | 14:26 | |
| TestDuration | Duration | 0:59:23 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
