Test Date: 2016-10-27 11:28
Analysis date: 2016-10-27 12:34
Analysis date: 2016-10-27 12:34
M1042 XRayHRQualification
Summary
| Module | Module | M1042 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.54 | % |
| Noise | Mean Noise | 321 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.55 | 0.52 | 81.0 | 254.2 | 0 | 0/0 | 0 | 3790 | 333 | 829 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.55 | 0.5 | 78.8 | 243.3 | 0 | 0/0 | 0 | 3781 | 351 | 1103 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.61 | 0.26 | 75.5 | 237.8 | 0 | 0/0 | 0 | 3712 | 370 | 1365 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.53 | 0.26 | 48.3 | 147.7 | 0 | 0/0 | 0 | 3852 | 314 | 567 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.55 | 0.24 | 50.1 | 151.8 | 0 | 0/0 | 0 | 3764 | 322 | 718 |
|
Chip 5
|
A
|
1 | 0 | 99.81 | 99.56 | 0.27 | 63.3 | 193.9 | 1 | 0/0 | 0 | 3783 | 325 | 768 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.55 | 0.25 | 55.1 | 168.1 | 0 | 0/0 | 0 | 3799 | 340 | 907 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.60 | 0.23 | 43.0 | 132.4 | 0 | 0/0 | 0 | 3881 | 308 | 464 |
|
Chip 8
|
A
|
0 | 0 | 99.80 | 99.68 | 0.2 | 35.4 | 108.2 | 0 | 0/0 | 0 | 3940 | 279 | 247 |
|
Chip 9
|
A
|
0 | 0 | 99.82 | 99.22 | 0.3 | 38.3 | 117.1 | 0 | 0/0 | 0 | 3854 | 297 | 327 |
|
Chip 10
|
A
|
0 | 0 | 99.78 | 99.57 | 0.19 | 40.9 | 124.6 | 0 | 0/0 | 0 | 3890 | 299 | 392 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.50 | 0.19 | 42.1 | 128.5 | 0 | 0/0 | 0 | 3852 | 316 | 622 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.58 | 0.24 | 41.3 | 125.0 | 0 | 0/0 | 0 | 3611 | 301 | 454 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.54 | 0.29 | 54.7 | 167.1 | 0 | 0/0 | 0 | 3835 | 324 | 722 |
|
Chip 14
|
A
|
0 | 0 | 99.77 | 99.48 | 0.42 | 72.2 | 222.8 | 0 | 0/0 | 0 | 3774 | 342 | 1004 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.57 | 0.27 | 75.2 | 233.1 | 0 | 0/0 | 0 | 3810 | 321 | 682 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 0:58:33 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 48 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 3 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 |
