Test Date: 2016-10-27 10:25
Analysis date: 2016-10-27 11:32
Analysis date: 2016-10-27 11:32
M1045 XRayHRQualification
Summary
| Module | Module | M1045 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 329 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.11 | 0.27 | 60.8 | 183.3 | 0 | 0/0 | 0 | 3759 | 315 | 564 |
|
Chip 1
|
A
|
1 | 0 | 99.82 | 99.62 | 0.27 | 60.1 | 181.5 | 1 | 0/0 | 0 | 3828 | 305 | 458 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.62 | 0.21 | 67.5 | 206.5 | 0 | 0/0 | 0 | 3770 | 326 | 722 |
|
Chip 3
|
A
|
0 | 0 | 99.79 | 99.51 | 0.26 | 62.5 | 188.2 | 0 | 0/0 | 0 | 3530 | 347 | 1064 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.70 | 0.2 | 51.6 | 155.1 | 0 | 0/0 | 0 | 3847 | 297 | 395 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.52 | 0.32 | 75.8 | 233.4 | 0 | 0/0 | 0 | 3516 | 341 | 974 |
|
Chip 6
|
A
|
0 | 0 | 99.79 | 99.57 | 0.38 | 76.8 | 232.5 | 0 | 0/0 | 0 | 3801 | 326 | 728 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.59 | 0.34 | 94.2 | 288.2 | 0 | 0/0 | 0 | 3729 | 387 | 1646 |
|
Chip 8
|
A
|
1 | 0 | 99.81 | 99.51 | 0.38 | 85.2 | 258.0 | 1 | 0/0 | 0 | 3782 | 347 | 1027 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.57 | 0.32 | 71.3 | 216.3 | 0 | 0/0 | 0 | 3794 | 350 | 1097 |
|
Chip 10
|
A
|
0 | 0 | 99.81 | 99.55 | 0.19 | 63.7 | 192.5 | 0 | 0/0 | 0 | 3798 | 309 | 562 |
|
Chip 11
|
A
|
1 | 0 | 99.83 | 99.70 | 0.25 | 46.0 | 138.4 | 1 | 0/0 | 0 | 3837 | 297 | 389 |
|
Chip 12
|
A
|
0 | 0 | 99.80 | 99.74 | 0.22 | 50.2 | 150.9 | 0 | 0/0 | 0 | 3838 | 309 | 507 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.32 | 75.2 | 233.3 | 0 | 0/0 | 0 | 3760 | 355 | 1151 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.35 | 0.25 | 64.0 | 196.1 | 0 | 0/0 | 0 | 3806 | 335 | 899 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.51 | 0.27 | 65.1 | 200.7 | 0 | 0/0 | 0 | 3835 | 317 | 637 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 10:25 | |
| TestDuration | Duration | 0:57:24 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 47 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 3 | |
| channel_3_count | Channel 3 | 3 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
