Test Date: 2016-10-27 13:51
Analysis date: 2016-10-27 15:00
Analysis date: 2016-10-27 15:00
M1054 XRayHRQualification
Summary
| Module | Module | M1054 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 21 | |
| BumpBondingDefects | Bump Bonding Defects | 21 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.57 | % |
| Noise | Mean Noise | 331 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "100" | Rate "300" | BB def | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.78 | 99.54 | 0.31 | 70.3 | 212.4 | 0 | 0/0 | 0 | 3612 | 341 | 908 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.51 | 0.29 | 73.2 | 224.1 | 0 | 0/0 | 0 | 3523 | 353 | 1131 |
|
Chip 2
|
A
|
3 | 0 | 99.83 | 99.57 | 0.21 | 68.4 | 208.9 | 3 | 0/0 | 0 | 3785 | 323 | 771 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.62 | 0.19 | 61.6 | 187.7 | 0 | 0/0 | 0 | 3806 | 322 | 694 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.73 | 0.16 | 47.5 | 144.8 | 0 | 0/0 | 0 | 3589 | 300 | 404 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.55 | 0.39 | 79.5 | 246.8 | 0 | 0/0 | 0 | 3754 | 342 | 985 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.58 | 0.36 | 83.5 | 252.6 | 0 | 0/0 | 0 | 3764 | 350 | 1065 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.56 | 0.33 | 90.7 | 273.4 | 0 | 0/0 | 0 | 3816 | 330 | 830 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.58 | 0.35 | 79.5 | 244.1 | 0 | 0/0 | 0 | 3786 | 342 | 1012 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.57 | 0.3 | 71.6 | 217.4 | 0 | 0/0 | 0 | 3794 | 331 | 812 |
|
Chip 10
|
A
|
3 | 0 | 99.82 | 99.64 | 0.26 | 77.3 | 238.2 | 3 | 0/0 | 0 | 3519 | 318 | 680 |
|
Chip 11
|
A
|
3 | 0 | 99.82 | 99.56 | 0.23 | 61.7 | 186.0 | 3 | 0/0 | 0 | 3748 | 335 | 875 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.69 | 0.23 | 43.1 | 129.2 | 0 | 0/0 | 0 | 3870 | 293 | 342 |
|
Chip 13
|
A
|
12 | 0 | 99.83 | 99.47 | 0.19 | 56.1 | 170.1 | 12 | 0/0 | 0 | 3683 | 311 | 527 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.55 | 0.29 | 72.2 | 220.3 | 0 | 0/0 | 0 | 3538 | 355 | 1137 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.46 | 0.25 | 70.2 | 215.0 | 0 | 0/0 | 0 | 3775 | 356 | 1193 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-27 | |
| TestTime | Test Time | 13:51 | |
| TestDuration | Duration | 0:58:10 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.5-11-g3f3decf on branch master
